Uniview MW3575-U-E
3175.92 azn
Uniview
75"
4K
60Hz
IPS
Audio
Stokda yoxdur
Haqqında
UNV MW3575-U-E 75'' Smart Interactive Display
| Ölçü | 75" |
| Görüntü imkanı | 4K |
| Tezlik | 60Hz |
| Panel | IPS |
| Audio | Audio |
Ətraflı
| Panel | Description |
| Backlight | DLED backlight |
| Panel size | 75 inches |
| Resolution | 3840*2160 |
| Brightness (cd/m²) | 350 |
| Contrast Ratio | 1200:1 |
| Response Time (ms) | 8 |
| Color Support | 1.07B |
| Viewing Angle (H/V) | 178°/178° |
| System | Description |
| CPU | RK3588: 4-core A76 (2.4G) + 4-core A55 (1.8G) |
| CPU Frequency | 2.4GHz |
| RAM/ROM | DDR4: 8GB eMMC: 64GB |
| System Compatibility | Android 12.0 |
| Touch | Description |
| Touch Control | Infrared touch screen, 20-point multi-touch at most |
| Touch Precision (mm) | ±1 |
| Recognizable Object | 5 points 2mm |
| Glass | 4mm tempered glass, level 7 on Mohs hardness scale, anti-glare |
| Touch Response Time (ms) | ≤10 |
| Touchscreen Input | Opaque objects (e.g. finger, pen, etc.) |
| Interface | Description |
| Video Input | 3*HDMI IN (4K@60) |
| Video Output | 1*HDMI OUT (4K@60) |
| Audio Input | 1*AUDIO IN |
| Audio Output | 1*AUDIO OUT |
| Other Interfaces | 1*RS232、3* USB 3.0、1* USB Type C、1* USB Type B |
| Network | 2*RJ 45,10M/100M/1000M adaptive Ethernet Interfaces |
| Audio | Description |
| Frequency domain | 80Hz～20kHz |
| Speaker | Left channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) Right channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W) |
| Wi-Fi | Description |
| WiFi Configuration | Wi-Fi6 + Wi-Fi5 dual-module, supports 5G/2.4G |
| WiFi Performance | 30 m² coverage, 20m transmission distance in open space |
| Bluetooth | Description |
| Bluetooth Version | 5.2 |
| Bluetooth Performance | 10m transmission distance in open space |
| OSD | Description |
| Multi-Language | 24 (Simplified Chinese、Traditional Chinese、English、Japanese、Arabic、French、Spanish、Portuguese、German、Italian、Dutch、Polish、Korean、Catalan、Galician、Vietnamese、Bulgarian、Kazakh、Russian、Ukrainian、Thai、Uzbek、Hungarian、Croatian) |
| VESA | Description |
| Wall mount hole (mm) | 600*400 |
| Wall mount screw | 4-M8 screw hole |
| General | Description |
| Power Supply | AC 100 to 240V, 50/60Hz |
| Overall Power Consumption （W） | ≤320 (on without OPS) |
| Standby Power Consumption （W） | ＜0.5 |
| Product Dimensions （W*H*D）（mm） | 1720*1035*89 |
| Package Dimensions （W*H*D）（mm） | 2115*1336*222 |
| Weight（Kg） | Net weight: 50.0 Gross weight:58.8 |
| Operating Temperature | 0 to 50°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Storage temperature | -20 to 60°C |
| Storage humidity | 0% to 95% (non-condensing) |
| Accessories Included | 1*power cord、2*touch pen、1*quick guide |
