MS106LP
59.51 azn
Mercusys
5 Port
PoE
60 W
100mb/s
Haqqında
MERCUSYS MS106LP UN 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+
| Port sayı | 5 Port |
| PoE | PoE |
| PoE gücü | 60 W |
| Port sürəti | 100mb/s |
Ətraflı
| Category | Details |
|---|---|
| Standards and Protocols | IEEE 802.3x Flow Control |
| Dimensions | 99.8 × 98 × 25 mm |
| PoE Ports | RJ45 Standard: Compliant with 802.3 af/at Powered Devices PoE Ports: Port 1 - Port 4 PoE Power Budget: 40 W |
| Interfaces | 6× 10/100 Mbps Ports, Auto-Negotiation, Auto MDI/MDIX |
| External Power Supply | External Power Adapter (Output: 53.5V/0.81A) |
| Installation | Desktop Wall Mount |
| Data Rates | 10/100 Mbps at Half Duplex 20/200 Mbps at Full Duplex |
| Jumbo Frame | 2 KB |
| MAC Address Table | 2K |
| Max Power Consumption | 1.87W (220 V / 50 Hz, no PD connected) 44.8W (220 V / 50 Hz, with 40W PD connected) |
| Max Heat Dissipation | 6.34 BTH/h (no PD connected) 152.32 BTH/h (with 40W PD connected) |
| Package Contents | • 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ (MS106LP) • Power Adapter • Quick Installation Guide |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% RH non-condensing Storage Humidity: 5%~95% RH non-condensing |
