Hikvision DS-KIS603-P(C)
428.03 azn
Hikvision
IP
KİT
WIFI
PoE
SD Card
Metal
Stokda yoxdur
Haqqında
Hikvision IP domofon DS-KIS603-P(C) kit; 7" TFT; 1024 × 600; WIFI; Plastik; PoE; Mikro SD; IC Card: 10000; Bucaq - 131°; IP653
| Bağlantı tipi | IP |
| Cihaz | KİT |
| WIFI | WIFI |
| PoE | PoE |
| Yaddaş | SD Card |
| Material | Metal |
Ətraflı
Screen Options
| Screen | 7″ color TFT LCD screen |
| Maximum screen resolution | 1024×600 |
| Working method | Touch screen, physical buttons |
Audio
| Audio input | Built-in omnidirectional microphone |
| Audio output | Built-in speaker |
| Audio compression | G.711 U, 64 Kbps |
| Audio quality | Noise and Echo Reduction |
Network settings
| Wired network | 10 / 100 MB adaptive |
| Wireless network | Wi-Fi 802.11b/g/n |
| Network protocols | TCP/IP, SIP, RTSP |
| Network interface | 1RJ45 10M/ 100M interface |
| Alarm inputs | 8 |
| TF card | Up to 32 GB, SD 2.0 or earlier |
| Power interface | 2 |
Basics
| Power supply | DC 12V, 1A PoE IEEE802.3 af |
| Power consumption | ≤ 6 W |
| Working conditions | From -10 to +55 °C, humidity from 10 to 90% |
| Dimensions | 200 × 140 × 15.1 mm |
model
System parameters
| operating system | Embedded Linux OS |
| Inner memory | 32 MB |
| Memory | 256 MB |
| CPU | Embedded MCU processor |
Display options
| Screen size | / |
| Control | / |
| Type | / |
| Permission | / |
Video options
| Lens | 1 |
| Permission | Main stream: 1920 × 1080p, 720p Sub stream: 704 × 576 |
| Viewing angle | Horizontal: 131° Vertical: 78° |
| WDR | True WDR |
| Additional lighting | IR illumination |
| Video compression standard | H.264 |
Audio options
| Audio compression standard | G.711 U |
| Audio input | Built-in omnidirectional microphone |
| Audio output | Built-in speaker |
| Audio bitrate | 64 Kbps |
| Improved sound quality | Noise and echo reduction |
| Volume adjustment | Customizable |
Capacity
| Number of users | 2000 |
| Number of face images | / |
| Number of cards | 10000 |
Network settings
| Communication protocol | TCP/IP, RSTP |
| Wired network | Auto 10 / 100 M Ethernet |
| Wi-Fi standard | Supported |
| Bluetooth | Not supported |
| 3G/4G standard | / |
Device interfaces
| Alarm input | 4 |
| Network interface | 1 |
| Tamper | 1 |
| Exit button | 1 |
| RS-485 | 0 |
| USB | 0 |
| Wiegand | 0 |
| TF card | Reserved |
| Alarm output | 0 |
| Door lock indicator | 1 |
| Door contact input | 1 |
| Power interface | 1 |
Basics
| Button | 1 |
| Installation | Overhead installation |
| Indicator | 2 |
| Weight | 265 g |
| Protection level | IP65 |
| Working temperature | -40 to +53 °C |
| Operating humidity | From 10 to 95% |
| Dimensions | 138 × 65 × 27 mm |
| Battery | / |
| terms of Use | Outside the premises |
| Power consumption | ＜ 10W |
| Language | English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian |
