HAC-HFW1500CP-A-0280B

HAC-HFW1500CP-A-0280B

Haqqında

Dahua HAC-HFW1500CP-A-0280B 5 MP HD-CVI səsli kamera; Piksel 2880x1620; IR işıqlandırma - 30 m; F2,8 mm; Bucaq-111°; Audio (mikrofon)

Növ Analoq
Meqapixel 5 MP
Obyektiv Sabit
Fokus 2.8
İşıqlandırma İR
İşıqlandırma məsafəsi 30 m
Mikrofon Mic
Qoruma IP67
Material Plastik

Ətraflı

Camera
Image Sensor1/2.7 inch CMOS
Max. Resolution2880 (H) × 1620 (V)
Pixel5MP
Scanning SystemProgressive
Electronic Shutter SpeedPAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
S/N Ratio>65 dB
Min. Illumination0.005 Lux/F1.6, 30IRE, 0 Lux IR on
Illumination Distance30 m (98.4 ft)
Illuminator On/Off ControlAuto; manual
Illuminator Number3
Pan/Tilt/Rotation RangePan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens TypeFixed-focal
Mount TypeM12
Focal Length2.8 mm; 3.6 mm
Max. ApertureF1.6
Field of View

2.8 mm: 132° × 111° × 58°

(diagonal × horizontal × vertical)

3.6 mm: 109° × 92° × 48°

(diagonal × horizontal × vertical)

Iris TypeFixed iris
Close Focus Distance

2.8 mm: 0.9 m (3.0 ft)

3.6 mm: 1.6 m (5.2 ft)

DORI DistanceLensDetectObserveRecognizeIdentify
2.8 mm63.6 m (208.7 ft)

25.4 m

(83.3 ft)

12.7 m

(41.7 ft)

6.4 m

(21.0ft)

3.6 mm

80 m

(262.5 ft)

32 m

(105.0 ft)

16 m

(52.5 ft)

8 m

(26.2 ft)

Video
Frame Rate

CVI:

PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps;

NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps

AHD:

PAL: 4M@25 fps;

NTSC: 4M@30 fps

TVI:

PAL: 4M@25 fps;

NTSC: 4M@30 fps

CVBS:

PAL: 960H;

NTSC: 960H

Resolution5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480)
Day/NightAuto switch by ICR
BLCBLC/HLC/DWDR
WDRDWDR
White BalanceAuto; manual
Gain ControlAuto; manual
Noise Reduction2D NR
Smart IRYes
MirrorOff/On
Privacy MaskingOff/On (8 area, rectangle)
Certifications
CertificationsCE (EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015, EN 55035:2017, EN 50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Audio InterfaceOne channel built-in mic (-A)
Video OutputVideo output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply12V ±30% DC
Power ConsumptionMax 3.7W (12V DC, IR on)
Environment
Operating Temperature-40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Storage Temperature-40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Protection GradeIP67
Structure
CasingPlastic throughout the whole casing
Camera Dimensions161.3mm×69.7mm×70.0mm(6.35"×2.75"×2.75" )
Net Weight0.19 kg (0.55 lb)
Gross Weight0.29 kg (0.64 lb)
