DS-T215(C)
471.03 azn
Hiwatch
Analoq
2 MP
PTZ
İR
100m
IP66
Metal
Stokda yoxdur
Haqqında
DS-T215(C) 5-75mm 2mp Optical Zoom 15X IR 100m HD Analog PTZ Kamera HiWatch
| Növ | Analoq |
| Meqapixel | 2 MP |
| Obyektiv | PTZ |
| İşıqlandırma | İR |
| İşıqlandırma məsafəsi | 100m |
| Qoruma | IP66 |
| Material | Metal |
Ətraflı
Camera
| Matrix | 1/2.8 Progressive Scan CMOS |
| Number of effective pixels | 1920x1080 |
| Sensitivity | Color: 0.005Lux@(F1.6,AGC ON), 0Lux with IR B&W: 0.001 Lux @(F1.6,AGC ON) |
| Electronic shutter speed | 1s ~ 1/10000s |
| Main thread | 25 fps (1920x1080) |
| Day/Night mode | Mechanical IR cut filter with auto-switching |
Lens
| Focal length | 5–75 mm, 15x |
| Zoom | 2.4s (optical Wide-Tele) |
| Lens viewing angle | Horizontal 53.8° - 4° Vertical 31.9° - 2.3° Diagonal 60.4° - 4.6° |
| Minimum working focusing distance | 10 ~ 1500mm (Wide-Tele) |
| Diaphragm | F1.6 - F3.5 |
| Focusing | Auto/ semi-automatic/ manual/region |
Pan and tilt
| Turning range | 360° |
| Rotational speed | Manual: 0.1° - 80°/s, preset: 80°/s |
| Tilt range | -15° - 90° (auto-flip) |
| Tilt speed | Manual: 0.1° - 80°/s, preset: 80°/s |
| Presets | 256 |
| Patrols | 10, up to 32 presets each |
| Templates | 5 templates, total recording time no less than 10 minutes |
| Actions during downtime | Preset, Patrol, Pattern, Vertical Scan, Horizontal Scan, Panoramic Scan |
| Scheduled actions | Preset, Patrol, Pattern, Vertical Scan, Horizontal Scan, Panoramic Scan |
| Power-off memory | Supported |
OSD menu
| A.G.C. | Auto/manual |
| White balance | Auto/Manual/ATW/Indoor/Outdoor |
| Masking | 8 areas |
| Image enhancement | WDR 120dB, BLC, 3D DNR, HLC, EIS |
Interfaces
| Video output | 1 output switchable TVI/AHD/CVI/CVBS, BNC/ 1Vp-p composite (75 Ω/BNC) |
| RS-485 | Half-duplex mode. Protocols: HIKVISION, Pelco-P, Pelco-D |
| UTC | HIKVISION_C |
Basics
| Nutrition | DC12V |
| Power consumption | 20W max. |
| Working conditions | -40°С – 65°С, humidity no more than 90% |
| Protection | IP66 TVS 4000V Transient Voltage Suppressor for Lightning Protection |
| EXIR illumination range | Up to 100 m |
| EXIR illumination power | Automatically adjusts depending on zoom ratio |
| Housing material | Metal/plastic |
| Dimensions | Ø164.5 × 295 mm |
| Weight | 2 kg |
