DH-SD5A232XA-HNR
DH-SD5A232XA-HNR

1870.19 azn

Dahua
IP
2 MP
PTZ
2.7 - 13.5
İR
150m
IP67
Metal
1870.19

1

Səbətə at AZN

DH-SD5A232XA-HNR

DH-SD5A232XA-HNR

Haqqında

DAHUA - DH-SD5A232XA-HNR ( 32x zoom ) - 2MP Starlight IR WizSense Network PTZ Camera

Növ IP
Meqapixel 2 MP
Obyektiv PTZ
Fokus 2.7 - 13.5
İşıqlandırma İR
İşıqlandırma məsafəsi 150m
Qoruma IP67
Material Metal

Ətraflı

CameraDatasheet
Image Sensor1/2.8" STARVIS™ CMOS
Pixel2MP
Max. Resolution1920 (H) x 1080 (V)
ROM4 GB
RAM1 GB
Electronic Shutter Speed1/1 s–1/30000 s
Scanning SystemProgressive
Min. IlluminationColor: 0.005 Lux@F1.35
B/W: 0.0005 Lux@F1.35
0 Lux (IR on)
Illumination Distance150 m (492.13 ft)
Illuminator On/Off ControlZoom Prio/Manual/SmartIR
Illuminator Number4
Lens
Focal Length4.9 mm–156 mm
Max. ApertureF1.35–F4.4
Field of ViewH: 62.8°–2.2°; V: 36.7°–1.3°; D: 69.2°–2.6°
Optical Zoom32x
Focus ControlAuto/Semi-Auto/Manual
Close Focus Distance1 m–1.5 m (3.28 ft–4.92 ft)
Iris ControlAuto/Manual/Fixed
DORI DistanceDetectObserveRecognizeIdentify
2152 m (7060.37 ft)850 m (2788.71 ft)430 m (1410.76 ft)215 m (705.38 ft)
PTZ
Pan/Tilt RangePan: 0°–360° endless
Tilt: –15° to +90°, auto flip 180
Manual Control SpeedPan: 0.1°/s–300°/s
Tilt: 0.1°/s–200°/s
Preset SpeedPan: 400°/s
Tilt: 300°/s
Presets300
Tour8 (up to 32 presets per tour)
Pattern5
Scan5
Power-off MemorySupport
Idle MotionPreset/Tour/Pattern/Scanning
ProtocolDH-SD
Pelco-P/D (auto recognition)
Artificial Intelligence
Event TriggerMotion detection, video tampering, scene changing, Network disconnection, IP address conflict, illegal access, and storage anomaly.
IVSObject Abandoned/Missing
Smart CaptureSupport human, motor vehicle and non-motor vehicle image capture.
Perimeter ProtectionTripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.
Face DetectionSupport
Auto TrackingSupport
SMD PLUSSupport
Video
CompressionH.265; H.264B; H.264M; H.264H; MJPEG (Sub Stream); H.265+; H.264+
Streaming Capability3 streams
Resolution1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576); CIF (352×288)
Frame Rate

Main stream: 1080P/1.3M/720P (1–50/60 fps)

Sub stream 1: D1/CIF (1–25/30 fps)

Sub stream 2: 720P (1–25/30 fps)

Bit Rate ControlVariable/Constant
Bit RateH.264: 3 Kbps–20480 Kbps
H.265: 3 Kbps–20480 Kbps
Day/NightAuto (ICR)/Color/B/W
BLCSupport
WDR120 dB
HLCSupport
White BalanceAuto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp
Gain ControlAuto/Manual
Noise Reduction2D/3D
Motion DetectionSupport
Region of Interest (RoI)Support
Image StabilizationElectronic
DefogElectronic
Digital Zoom16x
Flip180°
Privacy MaskingUp to 24 areas, and up to 8 areas in the same view
S/N Ratio≥ 55 dB
Audio
CompressionG.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723
Network
EthernetRJ-45 (10/100Base-T)
ProtocolIPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP; RTMP
InteroperabilityONVIF Profile S&G&T; CGI
Streaming MethodUnicast/Multicast
User/Host20 (total bandwidth 64M)
StorageFTP; Micro SD card (256G); NAS
BrowserIE7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari
Management SoftwareSmart PSS; DSS; DMSS; Easy4ip; IVSS
Mobile PhoneIOS, Android
Certification
Certifications

CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014

UL: UL60950-1+CAN/CSA C22.2,No.60950-1

Port
Audio I/O1 (Line in; bare wire)/1 (Line out; bare wire)
Alarm I/O2/1
Power
Power SupplyDC 24 V/2.5 A ± 25%
PoE+ (802.3at)
Power ConsumptionBasic: 12W
Max: 20W
Environment
Operating Temperature–40°C to +70°C (–40°F to +158°F)
Operating Humidity≤ 95%
ProtectionIP67; IK10; 6000V lightning proof; surge protection; voltage transient protection
Structure
DimensionsΦ190 mm × 332 mm (Φ7.48" × 13.07")
Net Weight4.7 kg (10.36 lb)
Gross Weight8 kg (17.64 lb)
