IPC-HFW1239TL1P-A-IL-0280B
107.65 azn
Stokda yoxdur
Haqqında
DAHUA IPC-HFW1239TL1P-A-IL-0280B 2MP 2.8MM FULL-COLOR NETWORK KAMERA
| İş mühiti | Outdoor |
| Növ | IP |
| Meqapixel | 2 MP |
| İşıqlandırma | LED |
| Mikrofon | Mic |
| Obyektiv | Sabit |
| Fokus | 2.8mm |
| İşıqlandırma məsafəsi | 30 m |
| Qoruma | IP67 |
| Material | Plastik |
Ətraflı
| Image Sensor | 1/2.8" CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
Min. Illumination | 0.005 lux@F1.6 (Color,30 IRE) 0.0005 lux@F1.6 (B/W,30 IRE) 0 lux (Illuminator on) |
| S/N Ratio | >56 dB |
Illumination Distance | Up to 30 m (98.43ft) (IR LED) Upto 30 m (98.43 ft) (Warm light) |
| Illuminator On/Off Control | Auto;Manual |
| Illuminator Number | 2 (IR LED); 2 (Warm light) |
Angle Adjustment | Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° |
Human Detection | Support the classification and accurate detection of human |
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Stream Capability | 2 streams |
Resolution | 1080p (1920 ×1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
Video BitRate | H.264: 32 kbps–4096 kbps H.265: 12kbps–4096 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | DWDR |
White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto;Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4areas, rectangular) |
| Region of Interest (RoI) | Yes (4areas) |
| Smart Illumination | Yes |
Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Built-in MIC | Yes, built-in Mic |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
Alarm Event |
Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exception |
| Network Port | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P |
| Interoperability | ONVIF (Profile S; Profile T); CGI |
| User/Host | 6 (Total bandwidth: 24 M) |
| Storage | FTP |
| Browser | IE; Chrome; Firefox |
| Management Software | Smart PSS Lite; DSS; DMSS |
| Mobile Client | iOS;Android |
Cyber Security |
Configuration encryption;Trusted execution;Digest;Security logs;HTTPS;Trusted upgrade;WSSE;Trusted boot;Account lockout;Generation and importing of X.509 certification; Video encryption |
Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (onlysupported bythe sub stream) |
Smart Codec |
Smart H.265+; Smart H.264+ |
Video Frame Rate | Main stream: 1920× 1080@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream;for multiple streams, the values willbe subjected to the total encoding capacity. |
Certification | |
Certifications | CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| Power | |
| Power Supply | 12 VDC/PoE (802.3af) |
Power Consumption | Basic: 1.8 W (12 VDC); 2.3 W (PoE) Max. (H.265 +intelligence on+ WDR+ illuminator intensity): 6.3 W (12 VDC); 7.8 W (PoE) |
| Environment | |
| Operating Temperature | –40 °Cto +60 °C(–40 °F to+140 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °Cto +60 °C(–40 °F to+140 °F) |
| Storage Humidity | ≤95% |
| Protection | IP67 |
| Structure | |
| Casing Material | Metal+plastic |
Product Dimensions | 197.9 mm × 80.2 mm × 76.2 mm (7.79" × 3.16" × 3.00") (L ×W × H) |
| Net Weight | 0.31 kg (0.68 lb) |
| Gross Weight | 0.45 kg (0.99 lb) |
| Lens Type | Fixed-focal | ||||
| Lens Mount | M12 | ||||
| Focal Length | 2.8 mm;3.6 mm | ||||
| Max. Aperture | F1.6 | ||||
Field of View | 2.8 mm: H: 104°; V: 55°; D: 124° 3.6mm: H: 88°;V: 44°; D: 105° | ||||
| Iris Control | Fixed | ||||
Close FocusDistance | 2.8 mm: 0.8 m (2.62ft) 3.6mm: 1.3 m (4.27 ft) | ||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify |
2.8 mm | 44.1 m (144.69 ft) | 17.7 m (58.07 ft) | 8.8 m (28.87 ft) | 4.4 m (14.44 ft) | |
3.6 mm | 58.9 m (193.24 ft) | 23.6 m (77.43 ft) | 11.8 m (38.71 ft) | 5.9 m (19.36 ft) | |
