Genata GNT-P9828V6
102.78 azn
Stokda yoxdur
Haqqında
GNT-P9828V6 8p 2Up-Link 250m AI Hybrid PoE Switch Genata
| PoE gücü | 120 W |
| Port sayı | 8 Port |
| PoE | PoE |
| Port sürəti | 100mb/s |
Ətraflı
| DATA SHEET | |
| Port | 2*100Mbps Uplink ports +8*100Mbps PoE ports |
| Transmission Rate | 2000Mbps Full Duplex; 10 or 100 or 1000Mbps Half Duplex |
| Max transmission distance | 130m |
| Power support | Power input: AC 110~220V Total≤120W
PoE Watchdog: Port 1-8 Power output: PoE1~6Port:1/2(+52V),3/6(GND)≤30W PoE7~8Port:1245(+53V),3678(GND) compatible1/2(+52V),3/6(GND)≤60W |
| Ports(1-6)Support | IEEE 802.3af/at protocol |
| Ports(7-8)Support | IEEE 802.3af/at/bt protocol |
| Performance Specification | Bandwidth: 2 Gbps |
| Network Latency (10 to 1000Mbps): ≦16μs (use the 64byte package size) | |
| MAC address table: 2K | |
The Frame Filter & Transmission Rate: 14800pps the most for 10M port, 148800pps the most for 100M port,1488000pps the most for 1000M port | |
| Networking Standard | IEEE 802.3i 10BASE-T |
| IEEE 802.3u 100BASE-TX/ IEEE 802.3ab 1000BASE-T | |
| IEEE 802.3xFlowControl | |
| IEEE 802.3af/at/bt Power over Ethernet | |
| Protection Level | Lightning Protection:6KV, Per: IEC61000-4-5 ESD Protection:8KV, Per: IEC61000-4-2 |
| Physical Specifications | Size(L*W*H)：187mm*139mm*43mm |
| Working Environment | Operating Temperature: -30℃ ~60℃ |
| Storage Temperature: -40℃ ~70℃ | |
| Operating Humidity: 10%~90% non-condensing | |
| Storage Humidity: 5%~90% non-condensing | |
| Electromagnetic Compatibility | CE mark |
| FCC Part15，Class B | |
| VCCI Class BEN55022 (CISPR 22) | |
| C-Tick | |
| Other Functions | Short-circuit protection |
| Over-Temperature protection | |
| Preventing surge | |
| Package Content | AC Power Cable、Installation Manual |
102.78 azn
Stokda yoxdur
