IPC-HDBW4431FP-AS-0280B
IPC-HDBW4431FP-AS-0280B

263.53 azn

Dahua
IP
4 MP
Mic
Sabit
2.8
İR
20 m
IP67
Metal
263.53

1

Səbətə at AZN

IPC-HDBW4431FP-AS-0280B

IPC-HDBW4431FP-AS-0280B

Haqqında

Dahua IPC-HDBW4431FP-AS-0280B 4 MP səsli IP kamera; Piksel 2688×1520; IR işıqlandırma - 20 m; F2.8 mm; Bucaq-104°; Audio (Mikrofon)

Növ IP
Meqapixel 4 MP
Mikrofon Mic
Obyektiv Sabit
Fokus 2.8
İşıqlandırma İR
İşıqlandırma məsafəsi 20 m
Qoruma IP67
Material Metal

Ətraflı

Camera
Image Sensor1/3” 4Megapixel progressive scan CMOS
Effective Pixels2688(H)x1520(V)
RAM/ROM512MB/32MB
Scanning SystemProgressive
Electronic Shutter SpeedElectronic Shutter Speed
Minimum Illumination

0.08Lux/F2.0( Color,1/3s,30IRE)

0.3Lux/2.0( Color,1/30s,30IRE)

0Lux/F2.0(IR on)

S/N RatioMore than 50dB
IR DistanceDistance up to 20m (66ft)
IR On/Off ControlAuto/ Manual
IR LEDs10
Lens
Lens TypeFixed
Mount TypeBoard-in
Focal Length2.8mm (3.6mm, 6mm optional)
Max. ApertureF2.0 (F2.0, F2.0)
Angle of ViewH: 104° (87°, 55°), V:57° (48°, 31°)
Optical ZoomN/A
Focus ControlFixed
Close Focus DistanceN/A
DORI DistanceLensDetectObserveRecognizeIdentify
2.8 mm63m(207ft)25m(82ft)13m(43ft)6m(20ft)
3.6 mm80m(262ft)32m(105ft)16m(52ft)8m(26ft)
6.0 mm117m(384ft)47m(154ft)23m(75ft)12m(39ft)
Pan/Tilt/Rotation
Pan/Tilt/Rotation RangePan:0˚~60˚; Tilt:0˚~80˚; Rotation:0˚~360˚
Intelligence
IVSTripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent FunctionsFace Detection
Video
CompressionH.265+/H.265/H.264+/H.264
Streaming Capability3 Streams
Resolution

4M(2688×1520)/3M(2304×1296)/

1080P(1920×1080)/1.3M(1280x960)/

720P(1280×720)/D1(704×576/704×480)/

VGA(640×480)/CIF(352×288/352×240)

Frame RateMain Stream: 4M(1~25/30fps)
Sub Stream: D1(1~25/30fps)
Third Stream: 720P(1~25/30fps)
Bit Rate ControlCBR/VBR
Bit Rate

H.264: 24~10240Kbps

H.265: 14~9984Kbps

Day/NightAuto(ICR) / Color / B/W
BLC ModeBLC / HLC / WDR(120dB)
White BalanceAuto/Natural/Street Lamp/Outdoor/Manual
Gain ControlAuto/Manual
Noise Reduction3D DNR
Motion DetetionOff / On (4 Zone, Rectangle)
Region of InterestOff / On (4 Zone)
Electronic Image Stabilization (EIS)N/A
Smart IRSupport
DefogN/A
Digital Zoom16x
Flip0°/90°/180°/270°
MirrorOff / On
Privacy MaskingOff / On (4 Area, Rectangle)
Audio
CompressionG.711a/ G.711Mu/ AAC/ G.726
Network
EthernetRJ-45 (10/100Base-T)/M12 D-Coding
Protocol

HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;

FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;

UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;

IGMP; SNMP

InteroperabilityONVIF, PSIA, CGI
Streaming MethodUnicast / Multicast
Max. User Access10 Users /20 Users
Edge Storage

NAS

Local PC for instant recording

Mirco SD card 128GB

Web ViewerIE, Chrome, Firefox, Safari
Management SoftwareSmart PSS, DSS, Easy4ip
Smart PhoneIOS, Android
Certifications
Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

E-mark(ECE-Regulation No.10)

EN50155(Optional)

Interface
Video InterfaceN/A
Audio InterfaceBuilt-in Mic
RS485N/A
AlarmN/A
Electrical
Power SupplyDC12V, PoE (802.3af)(Class 0)
Power Consumption<4.5W
Environmental
Operating Conditions-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress ProtectionIP67
Vandal ResistanceIK10
Construction
CasingMetal
DimensionsΦ106mm×50.3mm (4.17”×1.98”)
Net Weight0.4kg (0.88lb)
Gross Weight0.44kg (0.97lb)
