DH-HAC-HFW1239TUP-Z-A-LED

DH-HAC-HFW1239TUP-Z-A-LED

Haqqında

DAHUA DH-HAC-HFW1239TUP-Z-A-LED-27135-S2- 2MP FULL COLOR HDCVI KAMERA

İş mühiti Outdoor
Növ Analoq
Meqapixel 2 MP
Obyektiv Motorized
Fokus 2.7 - 13.5mm
İşıqlandırma LED
İşıqlandırma məsafəsi 60 m
Mikrofon Mic
Qoruma IP67
Material Metal

Ətraflı

Camera
Image Sensor1/2.8" CMOS
Max. Resolution1920 (H) × 1080 (V)
Pixel2MP
Scanning SystemProgressive
Electronic Shutter SpeedPAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
S/N Ratio>65 dB
Min. Illumination0.001 Lux/F1.2, 30IRE, 0 Lux LED on
Illumination Distance60 m (196.9 ft)
Illuminator On/Off ControlAuto; manual
Illuminator Number4
Pan/Tilt/Rotation RangePan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens TypeMotorized vari-focal
Auto FocusForks
Mount Typeφ16
Focal Length2.7 mm–13.5 mm
Max. ApertureF1.2
Field of ViewDiagonal: 39°–130°
Horizontal: 34°–107°
Vertical: 19°–56°
Iris TypeFixed iris
Close Focus Distance1.5 m (4.9 ft)
DORI DistanceLensDetectObserveRecognizeIdentify
2.7 mm44.9 m (147.3 ft)17.9 m (58.7 ft)

8.9 m

(29.2 ft)

4.5 m

(14.8 ft)

13.5 mm128.6 m (421.9 ft)51.4 m (168.6 ft)25.7 m (84.3 ft)12.8 m (42 ft)
Video
Frame RateCVI:
PAL: 1080p@25fps;
NTSC: 1080p@30fps;
AHD:
PAL: 1080p@25fps;
NTSC: 1080p@30fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30fps;
CVBS:
PAL: 960 × 576H;
NTSC: 960×480H;
Resolution1080P (1920 × 1080); 960H (960×576/960×480);
BLCBLC/WDR/HLC
WDR130 dB
White BalanceAuto; Area WB
Gain ControlAuto; manual
Noise Reduction3D NR
Smart LightForks
MirrorOff/On
Privacy MaskingOff/On (8 area, rectangle)
Certifications
CertificationsCE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Port



Video OutputVideo output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio InputOne channel built-in mic
Power
Power SupplyDC 12V ±30%
Power ConsumptionMax 10.2W (12V DC, LED on)
Environment
Temperature–30°C to +60°C (-22°F to 140°F); < 95% (non-condensation)
Storage Temperature–30°C to +60°C (-22°F to 140°F); < 95% (non-condensation)
Protection GradeIP67
Structure
CasingMetal throughout the whole casing
Camera Dimensions244.1mm × 90.4mm × 90.4mm (9.61" × 3.56" × 3.56")
Net Weight0.79 kg (1.7 lb)
Gross Weight1.07 kg (2.4 lb)
