IPC-HFW1431SP-0280B
144.51 azn
Dahua
IP67
IP
4 MP
30 m
Sabit
2.8mm
İR
Plastik
Outdoor
Haqqında
DAHUA - IPC-HFW1431SP (2.8MM ) 4MP NETWORK KAMERA
| Qoruma | IP67 |
| Növ | IP |
| Meqapixel | 4 MP |
| İşıqlandırma məsafəsi | 30 m |
| Obyektiv | Sabit |
| Fokus | 2.8mm |
| İşıqlandırma | İR |
| Material | Plastik |
| İş mühiti | Outdoor |
Ətraflı
| TechnicalSpecification | |
| Camera | |
| Image Sensor | 1/3” 4Megapixel progresive CMOS |
| Effective Pixels | 2688(H)x1520(V) |
| RAM/ROM | 512MB/32MB |
| Scanning System | Progressive |
| Electronic ShutterSpeed | Auto/Manual, 1/3~1/100000s |
Minimum Illumination | 0.08Lux/F2.0( Color,1/3s,30IRE) 0.3Lux/F2.0( Color,1/30s,30IRE) 0Lux/F2.0(IR on) |
| S/N Ratio | More than 50dB |
| IR Distance | Distance up to 30m(98ft) |
| IR On/Off Control | Auto/ Manual |
| IR LEDs | 18 |
| Lens | |
| Lens Type | Fixed |
| Mount Type | Board-in |
| Focal Length | 2.8 mm (3.6 mm optional) |
| Max. Aperture | F2.0/F2.0 |
| Angle of View | H:104°/87°, V:57°/48° |
| Focus Control | Fixed |
| Close FocusDistance | N/A |
| PTZ | |
| Pan/Tilt Range | Pan:0° ~360°;Tilt:0° ~90° ;Rotation:0° ~360° |
| Intelligence | |
Event Trigger | Motion detection, Video tampering, Scene changing, Network disconnection, Ip address conflict, Illegal access, Storage anomaly |
| IVS | Tripwire, Intrusion |
| Video | |
| Compression | H.265/H.264H/MJPEG(Sub Stream) |
| Smart Codec | Support H.265+/H.264+ |
| Streaming Capability | 2 Streams |
Resolution | 4M(2688x1520)/3M(2304×1296)/1080P(19 20×1080)/720P(1280×720)/VGA(640×480)/ D1(704×576/704×480)/CIF(352×288/352×240) |
Frame Rate | Main Stream:4M(1 ~ 20fps)/3M (1 ~ 25/30fps) |
| Sub Stream:D1(1 ~ 25/30fps) | |
| Bit Rate Control | CBR/VBR |
Bit Rate | H.265: 12K ~ 8448Kbps H.264: 32K ~ 10240Kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC Mode | BLC / HLC / WDR(120dB) |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off / On (4 Zone, Rectangle) |
| Region of Interest | Off / On (4 Zone) |
| Electronic Image Stabilization (EIS) |
N/A |
| Smart IR | Support |
| Digital Zoom | 16x |
| Flip | 0°/90°/180°/270° |
| Mirror | Off / On |
| Privacy Masking | Off / On (4 Area, Rectangle) |
| Audio | |
| Compression | N/A |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
Protocol | HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP; FTP; DHCP;DNS;DDNS;PPPoE;IPV4/V6;QoS;UPnP; NTP;Bonjour;IEEE 802.1X;Multicast;ICMP;IGMP;TLS |
| Interoperability | ONVIF ProfileS&G, API |
| Streaming Method | Unicast / Multicast |
| Max. UserAccess | 10 Users/ 20 Users |
Edge Storage | NAS Local PC forinstant recording |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS,DSS, DMSS |
| Smart Phone | IOS, Android |
| Certifications | |
Certifications | CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part15 Subpart B |
| Interface | |
| Video Interface | N/A |
| Audio Interface | N/A |
| RS485 | N/A |
| Alarm | N/A |
| Electrical | |
| Power Supply | DC12V, PoE(IEEE 802.3af)(Class 0) |
| Power Consumption | < 5.5W |
