XN020-G3V
65.01 azn
Tp-Link
GPON
2.4Ghz
1000 mb/s
WiFi4
Haqqında
TP -LINK XN020-G3V ARWISP 300MBPS WIRELESS N GIGABIT VOLP GPON ROUTER
| Tip | GPON |
| Tezlik | 2.4Ghz |
| Port sürəti | 1000 mb/s |
| WIFI | WiFi4 |
Ətraflı
| WIRELESS FEATURES | |
|---|---|
| Frequency | 2.4GHz |
| Signal Rate | 300Mbps at 2.4GHz |
| Transmit Power | <20dBm (2.4GHz) |
| Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Wireless Schedule | Support 2.4GHz Schedule |
| SOFTWARE FEATURES | |
|---|---|
| DHCP | Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
| Quality of Service | Hardware QoS |
| Port Forwarding | Virtual Server, Port Triggering, DMZ, ALG, UPnP |
| Dynamic DNS | DynDns, NO-IP |
| Security | NAT Firewall, SPI Firewall, Access Control, MAC/URL Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding |
| Advanced Functions | SN, Password, SN + Password Authentication Mode Upstream and Downstream FEC, AES encryption Dynamic Bandwidth Allocation(DBA) support NSR/SR 802.1Q VLAN, Static Routing; IGMP v1/v2 /v3 16 T-CONTs, 256 GEM Ports |
| Management | OMCI, Web Based Configuration, Command Line Interface, SSL for TR-069, OMCI Based Firmware Upgrade |
| IPSec VPN | Support up to 10 IPSec VPN tunnels |
| Protocols | Support IPv4 and IPv6 |
| WAN Connection Type | PPPoE, Dynamic IP, Static IP, Bridge |
| IGMP | IGMP v1/v2/v3 |
| OTHERS | |
|---|---|
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 , or other Java-enabled browser Cable or DSL Modem |
| Environment | Operating Temperature: 0℃~40℃(32℉~104℉) Storage Temperature: -40℃~70℃(-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Package Contents | 300Mbps Wireless N Gigabit VoIP GPON Router XN020-G3v RJ11 Phone Cable RJ45 Ethernet Cable Quick Installation Guide Power Adapter |
| Certifications | CE, Anatel |
| HARDWARE FEATURES | |
|---|---|
| Dimensions ( W x D x H ) | 7.1 ×4.9× 1.4 in. (181.5 ×125.7 ×36.2mm) |
| Antenna Gain | 2X2，2.4G 5dBi |
| Optical Module | Class C+ |
| Optical Wavelength | Transmit at 1310nm Receive at 1490nm |
| Transmission Distance | 0 ~ 20Km Max |
| Bandwidth | Downstream up to 2.488Gbps Upstream up to 1.244Gbps Max |
| Receiver | APD-TIA |
| Transmitter | DFB Laser |
| Interface | 1* SC/APC port 1* 10/100/1000Mbps LAN Port 1* 10/100Mbps LAN Port 1 FXS Port |
| Button | Power On/Off Button, Reset Button, WPS/Wi-Fi Buttion |
| External Power Supply | 12V/0.6A |
| IEEE Standards | IEEE 802.3, IEEE 802.3u, 802.3ab |
| Wireless Standards | IEEE 802.11g, 802.11b,802.11n |
| GPON Standards | ITU G.984.1 ITU G.984.2 ITU G.984.3 ITU G.984.4 |
