UAC-T132-F28
25.60 azn
Uniview
Analoq
2 MP
İR
20 m
Sabit
2.8
Plastik
Haqqında
HDTVI CAM UNV UAC-T132-F28 ( 2MP )
| Növ | Analoq |
| Meqapixel | 2 MP |
| İşıqlandırma | İR |
| İşıqlandırma məsafəsi | 20 m |
| Obyektiv | Sabit |
| Fokus | 2.8 |
| Material | Plastik |
Ətraflı
| Model | UAC-T132-F28 |
| Sensor | |
| Pixel | 2MP |
| Size | 1/3.2" |
| Minimum illumination | 0.02 lux (F2.0, AGC ON) 0 lux (IR ON) |
| Lens | |
| Lens | 2.8mm |
| Lens mount | M12 |
| Angle of view | H: 99.7° V: 55.1° D: 117.1° |
| Illuminator | |
| Illuminator | One IR illuminator |
| Illumination distance | 20m |
| Lifetime | ≥60,000 hours |
| Video | |
| Resolution | 1080P: 1920(H)×1080(V) 720P: 1280(H) ×720(V) |
| Frame rate | TVI/AHD/CVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps CVBS: PAL, NTSC |
| Shutter time | PAL: 1/25s-1/50000s NTSC: 1/30s–1/50000s |
| Image | |
| Exposure mode | Four modes: Global (default), BLC, HLC, DWDR |
| Day/Night | Three modes: Auto (default), Day, Night |
| Digital noise reduction | 2D/3D |
| White balance | Two modes: Auto (default), Manual |
| WDR | DWDR |
| Smart IR | Support |
| Flip | Supports 180° horizontal flip, 180° vertical flip |
| Defog | N/A |
| Audio | |
| Microphone | N/A |
| Camera audio | N/A |
| Interface | |
| Power | 5.5mm power interface |
| Video output | BNC, supports TVI/AHD/CVI/CVBS |
| Operating environment | |
| Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | ≤95% (RH, non-condensing) |
| Surge protection | 4kV |
| Ingress protection | N/A |
| General | |
| Power | DC 12V (±25%), with reverse polarity protection, Max 1.9W |
| Dimensions | Φ85mm*72mm (diameter*height) |
| Material | Plastic |
| Weight | 89.3g (0.20lb) |
| Certification | |
| EMC | CE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 55035) FCC (FCC 47 CFR part15 B) |
| Safety | CE-LVD (EN 62368-1) |
| Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU) |
