SD5A225XA-HNR-AC

SD5A225XA-HNR-AC

Haqqında

DAHUA SD5A225XA-HNR-AC 2MP 25X NETWORK PTZ KAMERA

Növ IP
Meqapixel 2 MP
Obyektiv PTZ
Fokus 2.7 - 13.5
İşıqlandırma İR
İşıqlandırma məsafəsi 150m
Qoruma IP67
Material Metal

Ətraflı

Camera
Image Sensor1/2.8" CMOS
Max. Resolution1920 (H) × 1080 (V)
Pixel2 MP
ROM4 GB
RAM1 GB
Electronic Shutter Speed1/3–1/30,000 s
Scanning SystemProgressive
Min. Illumination

Color: 0.005 Lux@F1.6

B/W: 0.0005 Lux@F1.6

0 Lux (IR light on)

Illumination Distance150 m (492.13 ft)
Illuminator On/Off ControlZoom Prio/Manual/SmartIR/Off
Illuminator Number4
Lens
Focal Length5.4 mm–135 mm
Max. ApertureF1.6-F3.5
Field of ViewH: 58.7°–3.1°; V: 33.2°–1.7°; D: 67.3°–3.9°
Optical Zoom25x
Focus ControlAuto/Semi-Auto/Manual
Close Focus Distance0.1 m–1.5 m (0.32 ft–4.92 ft)
Iris ControlAuto/Manual
DORI DistanceDetectObserveRecognizeIdentify
1655 m (5429.79 ft)657 m (2155.51 ft)331 m (1085.96 ft)166 m (544.62 ft)
PTZ
Pan/Tilt RangePan: 0°–360°; Tilt: -15°–+90°
Manual Control SpeedPan: 0.1°/s–300°/s; Tilt: 0.1°/s–200°/s
Preset SpeedPan: 400°/s; Tilt: 300°/s
Presets300
Tour8 (up to 32 preset per tour)
Pattern5
Scan5
Speed AdjustmentSupport
Power-off MemorySupport
Idle MotionPreset/Tour/Pattern/Scanning
ProtocolDH-SD
Pelco-P/D (Auto recognition)
General Intelligence
Event TriggerMotion detection, video tampering, scene changing, Network disconnection, IP address conflict, illegal access, and storage anomaly.
IVSObject Abandoned/Missing
Artificial Intelligence
Smart CaptureSupport human, motor vehicle and non-motor vehicle image capture.
Perimeter ProtectionTripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.
SMD PLUSSupport
Auto TrackingSupport
Face DetectionSupport
Video
CompressionH.265/H.265+/H.264+/H.264/MJPEG (Sub Stream)
Streaming Capability3 streams
Resolution1080p (1920 × 1080); 1.3 M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
Frame Rate

Main stream: 1080p/1.3 M/720p (1–50/60 fps)

Sub stream 1: D1/CIF (1–25/30 fps)

Sub stream 2: 1080p/1.3M/720p/D1/CIF (1–25/30 fps)

Bit Rate ControlVariable/Constant
Bit RateH.265/H.264: 3 kbps–20480 kbps
Day/NightAuto (ICR)/Color/B/W
BLCSupport
WDR120 dB
HLCSupport
White BalanceAuto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural/Street lamp
Gain ControlAuto/Manual
Noise Reduction2D/3D
Motion DetectionSupport
Region of Interest (RoI)Support
Image StabilizationElectronic
DefogSupport
Digital Zoom16x
Flip180°
Privacy MaskingUp to 24 areas, and up to 8 areas in the same view
Audio
CompressionG.711A; G.711Mu; G.726;AAC; MPEG2-Layer2; G.722.1; G.729; G.723
Network
Ethernet1 RJ-45 Port 10/100Base-T
ProtocolIPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP; RTMP
InteroperabilityONVIF Profile S&G&T; CGI
Streaming MethodUnicast/Multicast
User/Host20 (Total bandwidth 64M)
StorageFTP; Micro SD card (256G); NAS
BrowserIE7 and newer versions
Chrome 42 and older versions
Firefox 52 and older versions
Safari
Management SoftwareSmart Player / Smart PSS / DSS / Easy4ip
Mobile PhoneIOS/Android
Certification
Certifications

CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB,ANSI C63.4- 2014

UL:UL60950-1+CAN/CSA C22.2,No.60950-1

Port
Audio I/O1 (Line in; bare wire)/1 (Line out; bare wire)
Alarm I/O2/1
Power
Power Supply

AC 24 V/2.5 A ± 25%

PoE+ (802.3at)

Power Consumption

8 W

20 W (IR light on)

Environment
Operating Temperature–40 °C to +70 °C (–40 °F to +158 °F)
Operating Humidity≤ 95%RH
ProtectionIP67; IK10; TVS 6000V lightning protection; surge protection
Structure
CasingMetal
DimensionsΦ190 mm × 332 mm (7.48" × 13.07“)
Net Weight4.7 kg (10.36 lb)
Gross Weight8 kg (17.64 lb)
