UAC-B112-AF28-W
36.50 azn
Uniview
Analoq
2 MP
LED
20 m
Mic
Sabit
2.8
IP67
Plastik
Haqqında
HDTVI CAM UNV UAC-B112-AF28-W (2MP ColourHunter)
| Növ | Analoq |
| Meqapixel | 2 MP |
| İşıqlandırma | LED |
| İşıqlandırma məsafəsi | 20 m |
| Mikrofon | Mic |
| Obyektiv | Sabit |
| Fokus | 2.8 |
| Qoruma | IP67 |
| Material | Plastik |
Ətraflı
| Model | UAC-B112-AF28-W |
| Sensor | |
| Pixel | 2MP |
| Size | 1/3" |
| Minimum illumination | 0.01 lux (F1.6, AGC ON) 0 lux (white light on) |
| Lens | |
| Lens | 2.8mm |
| Lens mount | M12 |
| Angle of view | H: 100.9° V: 56.5° D: 121.8° |
| Illuminator | |
| Illuminator | One white-light illuminator |
| Illumination distance | 20m |
| Lifetime | ≥60,000 hours |
| Video | |
| Resolution | 1080P: 1920(H)×1080(V) 720P: 1280(H) ×720(V) |
| Frame rate | TVI/AHD/CVI: 1080P@25fps (default), 1080P@30fps, 720P@25fps, 720P@30fps CVBS: PAL, NTSC |
| Shutter time | PAL: 1/25s-1/50000s NTSC: 1/30s–1/50000s |
| Image | |
| Exposure mode | Four modes: Global (default), BLC, HLC, DWDR |
| Day/Night | 24/7 color images |
| Digital noise reduction | 2D/3D |
| White balance | Two modes: Auto (default), Manual |
| WDR | DWDR |
| Flip | Supports 180° horizontal flip, 180° vertical flip |
| Defog | N/A |
| Audio | |
| Microphone | Built-in Mic |
| Camera audio | TVI: 1080P@25fps, 1080P@30fps CVI: 1080P@25fps, 1080P@30fps |
| Interface | |
| Power | 5.5mm power interface |
| Video output | BNC, supports TVI/AHD/CVI/CVBS |
| Operating environment | |
| Temperature | -30℃ to 60℃(-22℉ to 140℉) |
| Humidity | ≤95% (RH, non-condensing) |
| Surge protection | 4KV |
| General | |
| Power | DC 12V(±25%), with reverse polarity protection, Max 2.3W |
| Mount | Surface mount (default), optional backbox, pole mount bracket |
| Dimensions | 142mm*63mm*65mm (L*W*H) |
| Material | Graphene+Plastic |
| Weight | 146g(0.32lb) |
| OSD menu language | 11 Languages English, German, Spanish(Latin America), French, Italian, Japanese, Korean, Polish, Portuguese(Brazil), Russian, Turkish |
| Certification | |
| EMC | CE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 55035) FCC (FCC 47 CFR part15 B) |
| Safety | CE-LVD (EN 62368-1) |
| Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) |
