NSW2020-10T-POE-IN
85.01 azn
Uniview
8 Port
100mb/s
PoE
100 W
Haqqında
NSW2020-10T-POE-IN 8PoE+2Port Ethernet Switch UNV
| Port sayı | 8 Port |
| Port sürəti | 100mb/s |
| PoE | PoE |
| PoE gücü | 100 W |
Ətraflı
| NSW2020-10T-POE-IN | |
| Hardware Specification | |
| Ports Type | 10×100Mbps network ports (RJ45), including 8 PoE ports |
| Prior Ports | 1~2 |
| Indicator | POWER Steady on: AC input is normal, POWER Off: No AC input, No PoE Indicator, PoE-MAX off: The POE power supply power of the whole machine is less than 80% of the specification, PoE-MAX Steady on : The POE power supply power of the whole machine is greater than 85% of the specification, LINK/ACT Off: No link, LINK/ACT Steady on: Linked, LINK/ACT Flashing: Transmitting data |
| PoE | support POE |
| Switching capacity | 2Gbps |
| Packet Buffer | 448K bit |
| Max. PoE Power | Max capacity: 88W, Max capacity for single port: 30W |
| Storage Temperature | -40 °C ~ 70 °C |
| Working Mode | Default(Normal mode) : All ports can communicate with each other., EXTEND(Surveillance mode): Transmission distance up to 250 meters. |
| Power Supply | DC: 48/51V, powered by adapter (AC100-240V, 50/60Hz) |
| Max.Power | 94W |
| Operating humidity | 10%～90% (noncondensing) |
| MAC | 1K |
| Forwarding performance | 1.49Mpps |
| Cooling Fans | 0 |
| Weight | 0.29KG |
| Storage humidity | 5%～90% (noncondensing) |
| Dimensions (W×D×H) | 171*103*25mm |
| Operating temperature | 0 °C ~ 40 °C (32 °F ~ 104 °F) |
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at |
