GNT-P4804F6
169.73 azn
Genata
120 W
8 Port
PoE
100mb/s
Haqqında
GNT-P4804F6 6pMb 2pGb +2SFP AI Waterproof PoE Switch Genata
| PoE gücü | 120 W |
| Port sayı | 8 Port |
| PoE | PoE |
| Port sürəti | 100mb/s |
Ətraflı
| Model | GNT-P4804F6 |
Ports | PoE (1~6):10/100Mbps PoE ports (RJ45) PoE (7~8):10/100/1000Mbps PoEports (RJ45),Support bt 60W HighPower LAN(1~2):10/100/1000Mbps uplink ports (RJ45) SFP:10/100/1000Mbps SFP port |
| Transmission Rate | 2000Mbps FullDuplex; 10 or 100 or 1000 MbpsHalf Duplex |
| Transmission Distance | 130m |
Performance Specification | Bandwidth:11.2Gbps |
| Network Latency(10 to 1000Mbps): ≦16μs (usethe 64byte packagesize) | |
| MAC address table: 8K | |
The FrameFilter & Transmission Rate: 14800pps the most for 10M port, 148800pps the most for 100M port;1488000pps the most for 1000M port | |
Networking Standard | IEEE 802.3i 10BASE-T/IEEE 802.3u100BASE-TX |
| IEEE 802.3ab 1000BASE-T | |
| IEEE 802.3x Flow Control | |
| IEEE 802.3af/at/bt Power over Ethernet | |
Power Support | Power Input:AC 90~240V Total≤120W AI Watchdog: Port 1~8 Power Output:PoE1~6 Port:1/2(+52V),3/6(GND)≤30W PoE7~8 Port:1245(+53V),3678(GND) Compatible1/2(+52V),3/6(GND)≤60W |
| Protection Level | Lightning Protection:6KV ESD Protection:8KV |
| Physical Specifications | Size(L*W*H): 310mm*260mm*100mm, Weight:1.6KG |
Working Environment | Operating Temperature: -30°C~60°C |
| Storage Temperature: -40°C~70°C | |
| Operating Humidity: 10%~90% Non-condensing | |
| Storage Humidity: 5%~90% Non-condensing | |
Certification | CE Mark |
| FCC Part15,Class B | |
| RoHS 2.0 | |
| Warranty | Whole Device:1 year |
| Package Content | AC Power Cable,User Manual |
