IPC-HFW1230TP-ZS-S4

IPC-HFW1230TP-ZS-S4

Haqqında

Dahua IPC-HFW1230TP-ZS-S4 2 MP IP zoom kamera; Piksel 1920×1080; IR işıqlandırma - 50 m; F2.8 - 12 mm; Bucaq-101°–33.5°;

Növ IP
Meqapixel 2 MP
Obyektiv Motorized
Fokus 2.7 - 13.5
İşıqlandırma İR
İşıqlandırma məsafəsi 50 m
Qoruma IP67
Material Metal

Ətraflı

Camera
Image Sensor1/2.8" CMOS
Max. Resolution1920 (H) × 1080 (V)
ROM16 MB
RAM128 MB
Scanning SystemProgressive
Electronic Shutter SpeedAuto/Manual 1/3 s–1/100,000 s
Min. Illumination

0.005 Lux@F1.5 (Color, 30 IRE)

0.0005 Lux@F1.5 (B/W, 30 IRE)

0 Lux (Illuminator on)

S/N Ratio> 56 dB
Illumination Distance50 m (164.04 ft) (IR)
Illuminator On/Off ControlAuto; Manual
Illuminator Number2 (IR)
Pan/Tilt/Rotation Range

Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°

Lens
Lens TypeMotorized vari-focal
Lens Mountφ14
Focal Length2.8 mm–12 mm
Max. ApertureF1.5
Field of View

Horizontal: 101°–33.5°; Vertical: 52.5°–19°;

Diagonal: 125°–38.5°

Iris ControlFixed
Close Focus Distance1.2 m (3.94 ft)
DORI DistanceLensDetectObserveRecognizeIdentify
W

48 m

(157.48 ft)

19 m

(62.34 ft)

10 m

( 32.81 ft)

5m

(16.40 ft)

T

131 m

(429.79 ft)

52 m

(170.60 ft)

26 m

( 85.30 ft)

13m

(42.65 ft)

Video
Video CompressionH.265; H.264; H.264B; MJPEG (Only supported by the sub stream)
Smart CodecSmart H.265+; Smart H.264+
Video Frame Rate

Main stream:1920 × 1080@1–25/30 fps

Sub stream: 704 × 576@1–25 fps/704 × 480@1–30 fps

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Stream Capability2 streams
Resolution1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate ControlCBR/VBR
Video Bit Rate

H.264: 32 kbps–6144 kbps

H.265: 12 kbps–6144 kbps

Day/NightAuto(ICR)/Color/B/W
BLCYes
HLCYes
WDRDWDR
Scene Self-adaptation (SSA)NA
White BalanceAuto; natural; street lamp; outdoor; manual; regional custom
Gain ControlAuto; manual
Noise Reduction3D NR
Motion DetectionOFF/ON (4 areas, rectangular)
Region of Interest (RoI)Yes (4 areas)
Smart IlluminationYes
Image Rotation0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
MirrorYes
Privacy Masking4 areas
Alarm
Alarm EventNo SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; security exception; defocus detection
Network
Network PortRJ-45 (10/100 Base-T)
SDK and APIYes
Cyber SecurityVideo encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
Network ProtocolIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast; DDNS
InteroperabilityONVIF (Profile S/Profile T); CGI; P2P; Milestone
User/Host6
StorageFTP; Micro SD card (Support max. 256 G)
Browser

IE

Chrome

Firefox

Management SoftwareSmart PSS; DSS; DMSS
Mobile ClientIOS; Android
Certification
Certifications

CE-LVD: EN60950-1

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

Power
Power Supply12 V DC; PoE
Power Consumption

Basic: 1.8W (12 V DC); 2.3W (PoE)

Max. (H.265 + ICR + IR intensity): 4.3 W (12V DC); 5.5 W (PoE)

Environment
Operating Temperature–30 °C to +60 °C (–22 °F to 140 °F)
Operating Humidity≤95%
Storage TemperatureNA
ProtectionIP67
Structure
CasingMetal
Product Dimensions244.1 mm × Ø90.4 mm (9.61" × Ø3.56")
Net Weight0.86 kg (1.90 lb)
Gross Weight1.12 kg (2.47 lb)
