HAC-ME1239THP-A-PV-0280B-S2
HAC-ME1239THP-A-PV-0280B-S2

136.01 azn

Dahua
Outdoor
Analoq
2 MP
LED
40 m
Sabit
2.8mm
Mic
IP67
Plastik
136.01

1

Səbətə at AZN

HAC-ME1239THP-A-PV-0280B-S2

HAC-ME1239THP-A-PV-0280B-S2

Haqqında

DAHUA HAC-ME1239THP-A-PV-0280B-S2 ( 2.8 MM ) - 2MP FULL COLOR HDCVI (OUTDOOR); Audio (səsli); Active Deterrence

İş mühiti Outdoor
Növ Analoq
Meqapixel 2 MP
İşıqlandırma LED
İşıqlandırma məsafəsi 40 m
Obyektiv Sabit
Fokus 2.8mm
Mikrofon Mic
Qoruma IP67
Material Plastik

Ətraflı

Camera
Pixel2 MP
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Scanning SystemProgressive
Electronic Shutter SpeedPAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s
Min. Illumination0.001 lux@F1.6 (Color, 30 IRE)
0.0001 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio>65 dB
Illumination DistanceIR: 40 m (131.23 ft)
Warm light: 40 m (131.23 ft)
Illuminator On/Off ControlAuto/Manual
Illuminator Number

2 (IR light)

2 (Warm light)

Pan/Tilt/Rotation RangePan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens TypeFixed-focal
Lens MountM12
Focal Length

2.8 mm

3.6 mm

Max. ApertureF1.6
Field of View

2.8 mm: H: 108°; V: 58°; D: 127°

3.6 mm: H: 86°; V: 46°; D: 101°

Iris ControlFixed
Close Focus Distance

2.8 mm: 0.7 m (2.29 ft)

3.6 mm: 1.1 m (3.61 ft)

DORI DistanceLensDetectObserveRecognizeIdentify
2.8 mm42.2 m (138.45 ft)

16.9 m

(55.45 ft)

8.4 m

(27.56 ft)

4.2 m

(13.78 ft)

3.6 mm53.7 m (176.18 ft)

21.5 m

(70.54 ft)

10.7 m

(35.10 ft)

5.4 m

(17.72 ft)

Video
Video Frame RateCVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960 × 576H;
NTSC: 960 × 480H
Resolution1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/NightAuto (ICR)/Color/B/W
BLCBLC; HLC; WDR
WDR130 dB
White BalanceAuto; Area white balance
Gain ControlAuto/Manual
Noise Reduction3D NR
Smart IlluminationYes
MirrorOff/On
Privacy MaskingOff/On (8 areas, rectangle)
IlluminatorSmart IR&WL; WL Mode; IR Mode
Active Deterrence
Sound WarningAudio1: alarm
Audio2: No parking here
Audio3: Private land no entry.
Audio4: Warning zone keep off
Audio5: Welcome
Volume: high/medium/low;
duration: 5 s–60 s; 110 dB
Red/Blue Light WarningFlash: 5 s–60 s; frequency: high/medium/low
Certification
Certifications

CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+A11:2017)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL62368-1+CAN/CSA C22.2 No.62368-1-14)

Port
Video OutputVideo output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio InputOne channel built-in MIC (-A)
Power
Power Supply12 VDC ± 30% (It is recommended to use a power adapter to supply the power for one camera)
Power ConsumptionMax 7.6 W (12 VDC, IR on)
Environment
Operating Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity<95% (RH), non-condensing
Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F)
ProtectionIP67
Structure
Casing MaterialMetal front cover + plastic rear barrel + metal bracket
Product Dimensions240.7 mm × Φ90.7 mm (9.48" × Φ3.57")
Packaging Dimensions299 mm × 119 mm × 111 mm (11.77" × 4.69" × 4.37")
Net Weight0.44 kg (0.97 lb)
Gross Weight0.70 kg (1.54 lb)
InstallationWall mount; ceiling mount; vertical pole mount
