IPC-HDW1239VP-A-IL-0280B-S5-QH2
IPC-HDW1239VP-A-IL-0280B-S5-QH2

107.65 azn

Dahua
Indoor
IP
2 MP
LED
Mic
Sabit
2.8mm
30 m
IP67
Plastik

Stokda yoxdur

Səbətə at AZN

IPC-HDW1239VP-A-IL-0280B-S5-QH2

Stokda yoxdur
IPC-HDW1239VP-A-IL-0280B-S5-QH2

Haqqında

DAHUA IPC-HDW1239VP-A-IL-0280B-S5-QH2 2MP FULL-COLOR NETWORK KAMERA

İş mühiti Indoor
Növ IP
Meqapixel 2 MP
İşıqlandırma LED
Mikrofon Mic
Obyektiv Sabit
Fokus 2.8mm
İşıqlandırma məsafəsi 30 m
Qoruma IP67
Material Plastik

Ətraflı

Camera
Matrix1/2.8" CMOS, 2 MP
Effective pixels (H×V)1920×1080
ROM128 MB
RAM128 MB
ScanProgressive
Electronic shutterAuto, Manual (1/3 sec ~ 1/100000 sec)
Sensitivity0.005Lux (Color, F1.6, 30 IRE)
0.0005Lux (B/W, F1.6, 30 IRE)
0Lux (Backlight)

Signal/noise>56 dB
Backlight range≤30m(IR illumination)
≤30m(LED illumination)

Backlight controlAuto, manual
Backlight module1 IR diode
1 warm spectrum LED
Axes adjustmentPan: 0° ~ 360°
Tilt: 0° ~ 78°
Rotate: 0° ~ 360°

Lens
TypeFixed
Mounting typeBuilt-in (M12)
Focal length2.8mm / 3.6mm
DiaphragmF1.6
Field of viewHorizontal: 104° / 88°
Vertical: 55° / 44°
Diagonal: 124° / 105°

Aperture controlNo
Minimum focusing distance0.8 m / 1.3 m
Distance O.N.R.I. (DORI)Focal lengthDetectionObservationRecognitionIdentification
2.8 mm44.1 m17.7 m8.8 m4.4 m
3.6 mm58.9 m23.6 m11.8 m5.9 m
Professional video analytics
People DetectionSupports classification and accurate detection of people
Intelligent searchWorks with intelligent IP DVRs to perform precise intelligent search, event retrieval, and event-to-video linking
Video
Video compressionH.265, H.264 (Base, Main, High), MJPEG (on additional stream)
Optimized codecsH.265+, H.264+
Frame rateMain Stream: 1920×1080 @ 1 fps ~ 25 fps
Sub Stream 1: 704×576 @ 1 fps ~ 25 fps
*The values ​​shown for each video stream are maximum; when transmitting multiple video streams simultaneously, their frame rate will decrease depending on available computing resources.
Number of threads2
Frame formats1080p (1920×1080), 960p (1280×960), 720p (1280×720), D1 (704×576), VGA (640×480), CIF (352×288)
Video Stream ControlCBR, VBR
Video stream sizeH.264: 32Kbps ~ 4096Kbps
H.265: 12Kbps ~ 4096Kbps

Day/Night ModeSwitching IR filter (auto, manual)
Backlight compensationBLC, HLC
Wide dynamic rangeDWDR
White balanceAuto, natural, street lighting, street, manual, zonal
Signal amplificationAuto, manual
Noise reduction3D DNR
Motion detectionYes (4 zones)
Regions of Interest (RoI)Yes (4 zones)
Intelligent backlightYes
Rotate image90°, 180°, 270°
MirroringYes
Private areasYes (4 zones)
Audio
Built-in microphoneYes
Audio compressionG.711a, G.711mu, G.726, PCM
Signaling
Disturbing developmentsNetwork failure, IP conflict, unauthorized access, motion, lens tampering, audio detection alarm, SMD(people) alarm, security error
Net
EthernetRJ-45 (10 Mbit/s, 100 Mbit/s)
ProtocolsARP, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4, IPv6, Multicast, NTP, RTCP, RTP, RTSP, SMTP, TCP, UDP

SafetyConfiguration encryption, trusted execution, digest authentication, security logs, HTTPS, trusted update, WSSE, trusted boot, account lockout, X.509 certificate generation and import, video encryption

CompatibilityONVIF(S,T),CGI
SDK and APIYes
Maximum number of connections6 (total flow 24 Mbps)
Peripheral storageFTP
Web clients

Internet Explorer, Google Chrome, FireFox



ClientsSmart PSS Lite, DSS, DMSS
Mobile clientsiOS, Android
Certification
CertificatesEN62368-1 (EU Low Voltage Directive)
2014/30/EU (EU EMC)

Power supply
Nutrition12V (DC), PoE (802.3af)
Power consumptionBasic: 1.8 W (12 V), 2.3 W (PoE)
Maximum (H.265, video analytics, WDR, backlight): 4.5 W (12 V), 5.6 W (PoE)

terms of Use
Operating temperature-40°C ~ +60°C
Working humidity≤95%
Storage temperature-40°C ~ +60°C
Storage humidity≤95%
ProtectionIP67
Physical parameters
Body materialMetal, plastic
Dimensions

Ø 109.9 mm × 100.9 mm



WeightNet: 0.33 kg
Gross: 0.45 kg
