IPC-HDPW1230R1P-S4-0280B
IPC-HDPW1230R1P-S4-0280B

105.41 azn

Dahua
IP
2 MP
30 m
Sabit
2.8
İR
IP67
Plastik

Stokda yoxdur

Səbətə at AZN

IPC-HDPW1230R1P-S4-0280B

Stokda yoxdur
IPC-HDPW1230R1P-S4-0280B

Haqqında

Dahua IPC-HDPW1230R1P-S4-0280B 2 MP IP kamera; Piksel 1920×1080; IR işıqlandırma - 30 m; F2.8 mm; Bucaq-102°;

Növ IP
Meqapixel 2 MP
İşıqlandırma məsafəsi 30 m
Obyektiv Sabit
Fokus 2.8
İşıqlandırma İR
Qoruma IP67
Material Plastik

Ətraflı

Camera
Image Sensor1/2.8" CMOS
Max. Resolution1920 (H) × 1080 (V)
ROM16 MB
RAM64 MB
Scanning SystemProgressive
Electronic Shutter SpeedAuto/Manual 1/3 s–1/100000 s
Min. Illumination0.01 Lux @F2.0
S/N Ratio>56 dB
Illumination Distance30 m (98.4 ft)
Illuminator On/Off ControlAuto/Manual
Illuminator Number1 (IR LED)
Pan/Tilt/Rotation Range

Pan: 0°–355°

Tilt: 0° –75°

Rotation: 0°–355°

Lens
Lens TypeFixed-focal
Lens MountM12
Focal Length2.8 mm; 3.6 mm
Max. Aperture

2.8 mm: F2.0

3.6 mm: F2.0

Field of View

2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120°

3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100°

Iris ControlFixed
Close Focus Distance

2.8 mm: 0.5 m (1.6 ft)

3.6 mm: 0.8 m (2.6 ft)

DORI DistanceLensDetectObserveRecognizeIdentify
2.8 mm37.3 m
(122.4 ft)

14.9 m

(48.9 ft)

7.5 m

( 24.6 ft)

3.7 m
(12.1 ft)
3.6 mm

53.3 m

(174.9 ft)

21.3 m

(69.9 ft)

10.7 m
(35.1 ft)		5.3 m
(17.4 ft)
Video
Video CompressionH.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart CodecSmart H.265+/Smart H.264+
Video Frame Rate

Main Stream:

1920 × 1080 (1 fps–25/30 fps)

Sub stream:

704 × 576 (1 fps–25 fps)

704 × 480 (1 fps–30 fps)

Stream Capability2 streams
Resolution1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate ControlCBR/VBR
Video Bit Rate

H.264: 32 kbps–6144 kbps

H.265: 12 kbps–6400 kbps

Day/NightAuto (ICR)/Color/B/W
BLCYes
HLCYes
WDRDWDR
White BalanceAuto; natural; street lamp; outdoor; manual; regional custom
Gain ControlAuto/Manual
Noise Reduction3D NR
Motion DetectionOFF/ON (4 areas, rectangular)
Region of Interest (RoI)Yes (4 areas)
Smart IlluminationYes
Image Rotation0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
MirrorYes
Privacy Masking4 areas
Alarm
Alarm EventNetwork disconnection; IP conflict; illegal access; motion detection; video tampering; safety exception
Network
NetworkRJ-45 (10/100 Base-T)
SDK and APIYes
Cyber SecurityVideo encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
Network ProtocolIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast
InteroperabilityONVIF (Profile S/Profile T); CGI; P2P; Genetec
User/Host6 (Total bandwidth: 36 M)
StorageFTP
BrowserIE
Chrome
Firefox
Management SoftwareSmart PSS; DSS; DMSS
Mobile ClientIOS; Android
Certification
Certifications

CE-LVD: EN62368-1

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

Power
Power Supply12V DC/PoE (802.3af)
Power Consumption

Basic power consumption: 1.6W (12V DC); 2.4W (PoE)

Max. power consumption (ICR + H.265 + IR intensity): 3.9W (12V DC); 4.7W (PoE)

Environment
Operating Conditions-40°C to +60°C (-40°F to +140°F)/less than ≤ 95%
Storage Temperature-40°C to +60°C (-40°F to +140°F)
ProtectionIP67
Structure
CasingPlastic
Product Dimensions98.1 mm × Φ122 mm (3.9" × Φ4.8")
Net Weight0.34 kg (0.7 lb)
Gross Weight0.52 kg (1.1 lb)
