UAC-B112-AF28-DL
36.50 azn
Uniview
Outdoor
Analoq
2 MP
LED
20 m
Mic
Sabit
2.8mm
IP67
Plastik
Haqqında
HDTVI CAM UNV UAC-B112-AF28-DL 2MP ColorHunter Fixed Dual-light Bullet Analog Camera
| İş mühiti | Outdoor |
| Növ | Analoq |
| Meqapixel | 2 MP |
| İşıqlandırma | LED |
| İşıqlandırma məsafəsi | 20 m |
| Mikrofon | Mic |
| Obyektiv | Sabit |
| Fokus | 2.8mm |
| Qoruma | IP67 |
| Material | Plastik |
Ətraflı
| UAC-B112-AF28-DL | |
| Sensor | |
| Pixel | 2 MP |
| Sensor Size | 1/3.0" CMOS |
| Min. Illumination | 0.01 lux (F2.0, AGC ON) 0 lux (Illuminator ON) |
| Lens | |
| Focus | 2.8 mm |
| Lens Mount | M12 |
| Angle of View (H) | 91.5° |
| Angle of View (V) | 51.2° |
| Angle of View (D) | 106.3° |
| Illuminator | |
| Illuminator Number | Two IR illuminators; One white-light illuminator |
| Illumination Distance | IR: 20m (65.6 ft) White light: 20m (65.6 ft) |
| Lifetime | ≥ 60000 hours |
| Video | |
| Resolution | 1080P: 1920(H)×1080(V) 720P: 1280(H) ×720(V) |
| Frame Rate | TVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps AHD: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps CVI: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps CVBS: PAL, NTSC |
| Shutter Time | PAL: 1/25 s-1/50000 s, NTSC: 1/30 s-1/50000 s |
| Image | |
| Exposure Mode | Four modes: Global (default), BLC, HLC, DWDR |
| Day/Night | Three modes: Auto (default), Day, Night |
| Digital Noise Reduction | 2D/3D |
| White Balance | Two modes: Auto (default), Manual |
| WDR | DWDR |
| Light Mode | Dual light (default) , Infared, White light |
| Flip | Supports 180°horizontal flip, 180°vertical flip |
| Digital Defog | N/A |
| Audio | |
| Built-in Mic | Support |
| Camera Audio | TVI: 1080P@25fps, 1080P@30fps CVI: 1080P@25fps, 1080P@30fps |
| Interface | |
| Power Interface | 5.5 mm Power Interface |
| Video Output | BNC, supports TVI/AHD/CVI/CVBS |
| Operating Environment | |
| Temperature | -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉) |
| Humidity | ≤ 95% RH (non-condensing) |
| Surge Protection | 4 KV for power, 4 KV for video output interfaces |
| General | |
| Power | DC 12 V ± 25% |
| Power Consumption | MAX 2.8W |
| Mount | Corner Mount, Pole Mount |
| Dimensions | 140mm*61mm*65mm (L*W*H) |
| Material | Plastic |
| Weight | 142g (0.31lb) |
| OSD Menu Language | 11 Languages: English, German, Spanish (Latin America), French, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Turkish |
| Certification | |
| EMC | CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (FCC 47 CFR part15 B) |
| Safety | CE-LVD (EN 62368-1) |
| Environment | CE-RoHS (2011/65/EU; (EU) 2015/863); WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) |
