iDS-2CD7526G0-IZHS
1383.12 azn
Hikvision
2 MP
Varifokal
Mic
2.7 - 13.5
İR
30 m
IP67
Metal
Haqqında
| Meqapixel | 2 MP |
| Obyektiv | Varifokal |
| Mikrofon | Mic |
| Fokus | 2.7 - 13.5 |
| İşıqlandırma | İR |
| İşıqlandırma məsafəsi | 30 m |
| Qoruma | IP67 |
| Material | Metal |
Ətraflı
| Matrix | 1/1.8″ Progressive Scan CMOS |
| Sensitivity | Color: 0.001 lux @ (F1.2, AGC on); b/w: 0.0003 lux @ (F1.2, AGC on) |
| Electronic shutter speed | 1 to 1/100,000 s |
| Slow shutter support | Yes |
| P/N | P/N |
| Wide dynamic range WDR | 140 dB |
| Day/night mode | IR filter |
| Adjusting the viewing angle | Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 355° |
| Power-off position memory | Eat |
| Focusing | Automatic, semi-automatic, manual |
| Lens type and viewing angle | From 2.8 to 12 mm, horizontally: from 107.3 to 39.8°, vertically: from 55.9 to 22.3°, diagonally: from 130.1 to 45.7° From 8 to 32 mm, horizontally: from 40.3 to 14.4°, vertically: from 22.1 to 8.2°, diagonally: from 46.9 to 16.5° |
| Aperture | From 2.8 to 12 mm: F1.2 to F2.5 From 8 to 32 mm: from F1.7 to F1.73 |
| Lens mount | Built-in |
| Blue Glass Module | The module is used to reduce the backscattering effect |
| P-Iris | Yes |
| IR range | From 2.8 to 12 mm: 30 m From 8 to 32 mm: 50 m |
| Wavelength | 850 nm |
| Additional smart lighting | Yes |
| Maximum resolution | 1920×1080 |
| Main thread | 50 Hz: 50 fps (1920 × 1080, 1280 × 720) 60 Hz: 60 fps (1920 × 1080, 1280 × 720) |
| Additional stream | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Third stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fourth stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fifth stream | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Custom Flow | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Video compression | Main stream: H.265+/H.265/H.264+/H.264 Secondary Stream/Third Stream/Fourth Stream/Fifth Stream/Custom Stream: H.265/H.264/MJPEG |
| Video bitrate | From 32 Kbps to 16 Mbps |
| H.264 profile | Baseline Profile/Main Profile/High Profile |
| H.265 profile | Main Profile |
| H.264+ | For main thread |
| H.265+ | For main thread |
| Bitrate | CBR/VBR |
| Stream type | Main Stream/Secondary Stream/Third Stream/Fourth Stream/Fifth Stream/Custom Stream |
| S.V.C. | H.265 and H.264 supported |
| Region of interest (ROI) | 4 fixed areas for each thread |
| Environmental Noise Filter | Yes |
| Sampling frequency | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio bitrate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/32 Kbps (PCM)/from 8 to 320 Kbps (MP3) |
| Audio type | Mono |
| Simultaneous real-time viewing | Up to 20 channels |
| API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour , SSL/TLS |
| Smooth Streaming | Yes |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Safety | Password protection, strong password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermarking, IP address filtering, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, timeout management settings, security audit log, TLS 1.2 |
| Network storage | MicroSD/SDHC/SDXC card (256 GB) and NAS (NFS, SMB/CIFS), ANR Support for Hikvision memory card, encryption and diagnostics of memory card. |
| Client | HikCentral Pro (recommended), iVMS-4200, Hik-Connect, Hik-Central |
| Web interface | Requires live view plugin: IE8+ No plugin required for live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local services: Chrome 41.0+, Firefox 30.0+ |
| Intelligent IR illumination | The IR LEDs on the camera must support Intelligent IR to automatically adjust the power to prevent overexposure of the image. |
| Day/night mode | Day/Night/Automatic/Scheduled/Alarm |
| Cropping an image | Yes |
| Image overlay | Logo in bmp format 24 bit, size 128 x 128 |
| Image enhancement | BLC, HLC, 3D DNR, Anti-fog, EIS, distortion correction |
| Picture Options Switch | Eat |
| Image Settings | Corridor mode, saturation, brightness, contrast, sharpness, saturation and white balance are adjustable via client software or web interface |
| SNR | ≥ 52 dB |
| Alarm interface | 1 input, 1 output (max. DC 24 V, 1 A) |
| Audio | Without the letter -R: 1 input (line-in), 3.5 mm jack, max. input signal amplitude: 3.3 V p-p, input resistance: 4.7 kOhm; interface type: nonequilibrium; 1 output (line), 3.5 mm jack, max. output signal amplitude: 3.3 V p-p, output impedance: 100 Ohm, interface type: nonequilibrium, mono, 2 built-in microphones |
| RS-485 | Models with -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, adaptive) |
| Video output | 1V p-p composite output (75 ohm/CVBS), (debug only) |
| Local storage | Built-in slot for microSD/SDHC/SDXC card, up to 256 GB |
| Hard reset | Yes |
| Network interfaces | 1 RJ45 auto 10M/100M/1000M Ethernet |
| Power output | DC 12 V, max. 200 mA (supported by all types of power supplies) |
| Heater | Yes |
| Main events | Motion detection, tamper detection, vibration detection, exceptions (network interruption, IP address conflict, unauthorized login, drive full, drive error) |
| Smart Events | Line crossing, up to 4 customizable lines Invasion, up to 4 customizable areas Login to an area, up to 4 custom areas Exit area, up to 4 custom areas Abandoned baggage detection, up to 4 customizable areas Move an object, up to 4 customizable areas Scene change detection, audio event detection, defocus detection |
| Count | Yes |
| Face recognition | Detection of up to 30 faces simultaneously; Required facial position for detection: supported left and right rotation from -60 to +60°, up and down tilt from -30 to +30°; Up to 3 customizable libraries, 30,000 face images each; Human recognition using facial modeling, evaluation and comparison with images in the library; Encryption of the image library |
| Multiple Target Detection | Simultaneous detection of human figure and face Obtaining 8 characteristic features of the face and 13 characteristic features of the human figure |
| Counting faces | Counting the number of people entering/exiting (tracking 30 targets simultaneously); Face recognition; Dynamic updating and updating of face images in libraries 24/7 (up to 3 libraries, 30,000 face images in each); Generating an alarm when a face is detected for which there is already the same image in the library. |
| Helmet presence/absence detection | Simultaneous recognition of up to 30 human targets Detection of up to 4 protected areas |
| Queue management | Determining the number of people in the queue and the waiting time for each person Generate reports to compare the performance of different queues and show the changing status of one queue Support for exporting raw data for further analysis |
| Perimeter protection | Line crossing, intrusion detection, area entry, area exit Alarm triggering for various types of objects (person, vehicle) False alarm filter: no response to movement of foliage, animals, flags, etc. |
| Bind method | Upload to FTP/NAS/memory card, notify monitoring center, send email, trigger alarm output, alarm recording, image capture Alarm recording: memory card, network storage, pre-record and post-record Image upload: FTP, SFTP, HTTP, NAS, Email Trigger notifications: HTTP, ISAPI, alarm output, Email |
| Online update | Yes |
| Double backup | Yes |
| Firmware version | V5.5.121 |
| Web client language | 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Chinese (traditional), Thai, Vietnamese, Japanese, Latvian, Lithuanian, Brazilian Portuguese, Ukrainian |
| Main functions | Anti-Flicker, 5 installed streams and up to 5 custom streams, EPTZ, Heartbeat, mirroring, area masking, password change by e-mail, pixel counting |
| Soft reset | Yes |
| Storage conditions | -30 to +60 °C, humidity 95% or less (non-condensing) |
| Working conditions | -50 to +60 °C, humidity 95% or less (non-condensing) |
| Nutrition | Models with the letter -Y: DC 12V±20%, three-core terminal block, reverse polarity protection; AC 24V±20%, three-core terminal block, reverse polarity protection; PoE: 802.3 at, type 2, class 4 Models without the letter -Y: DC 12V±20%, three-core terminal block, reverse polarity protection; AC 24V±20%, three-core terminal block, reverse polarity protection; PoE: 802.3 at, type 2, class 4 |
| Power consumption | With additional load: DC 12 V, 1.16 A, max. 13.9 W; PoE: (802.3 at, 42.5 to 57 V), 0.33 to 0.25 A, class 4; Without additional load: DC 12 V, 0.98 A, 12.5 W; PoE: (802.3 at, 42.5 to 57 V), 0.3 to 0.22 A, class 4; * “With additional load” means that an additional device is connected to the camera. |
| Power interface | Models with the letter -Y: three-core terminal block Models without -Y: dual-core terminal block |
| Camera material | Aluminum alloy body |
| Screw material | SUS304 stainless steel |
| Camera size | Ø 162 × 141.8 mm (Ø 6.4 × 5.6″) |
| Packing size | 251 × 215 × 189 mm (9.9 × 8.5 × 7.4″) |
| Camera weight | Models without -Y: 1480 g Models with -Y: 1550 g |
| Weight with packaging | Models without -Y: 2407 g Models without -Y: 2206 g |
| Anti-glare dome | Yes |
| Metadata | Metadata for intrusion detection, line crossing, area entry/exit, abandoned items detection, object movement detection, face capture and queue management. |
| Class | Class B |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014) EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety. | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252 (Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Security Standards | Ingress protection: IP67 (IEC 60529-2013), IK10 (IEC 62262:2002) |
| Transport and railway standards | Models with -R: EN50121-4 |
| Anti-corrosion protection | -Y models: NEMA 4X: NEMA 250-2014 |
