GS2048PS4
2302.03 azn
Cudy
48 Port
Managed
PoE+
1000mb/s
720 W
Haqqında
Cudy GS2048PS4 48-Port L2 Managed Gigabit PoE Switch with 4 10G SFP slots
| Port sayı | 48 Port |
| Tip | Managed |
| PoE | PoE+ |
| Port sürəti | 1000mb/s |
| PoE gücü | 720 W |
Ətraflı
| Model | GS2048PS4 |
| İnterfeys | 48 10/100/1000Base-T portu 4 10Gigabit SFP+ portu 1 Konsol portu 1 USB portu 1 Sıfırlama düyməsi |
| LED göstəriciləri | PWR, PoE, Link/Act LED |
| Giriş gərginlikli | 100V~240V AC 50/60Hz |
| Enerji istehlakı | 750W (720W for PoE) |
| CPU | 400MHz ARM Cortex-A9 |
| DDR | 2G DDR3 800MHz |
| RAM | 256Mbits |
| Flash Memory | 64Mbits |
| İşləmə temperaturu | 0°C~40°C |
| Saxlama temperaturu | -40°C~70°C |
| Nisbi rütubət | 5%~95% (non-condensing) |
| Termal üsullar | Quraşdırılmış FAN |
| PoE | |
| PoE port | 48 PoE ports. 1-4 ports support IEEE802.3af/at/bt, 5-48 ports support IEEE802.3af/at |
| PoE Standart | IEEE 802.3af/at/bt |
| Pin təyinatı | IEEE 802.3af/at/: 2 pairs V+ (RJ45 Pin 3, 6), V- (RJ45 Pin 1, 2) IEEE 802.3bt/: 4 pairs V+ (RJ45 Pin 1, 2), V- (RJ45 Pin 3, 6) V+ (RJ45 Pin 4, 5), V- (RJ45 Pin 7, 8) |
| PoE management | Port-baza PoE statusuna baxmaq və nəzarəti dəstəkləyin |
| L2 Switching | |
| Kommutasiya qabiliyyəti | 176Gbps |
| Paket Buferi | 16Mbits |
| Məhsuldarlıq | 130.944Mpps |
| Port konfiqurasiyası | |
| Port auto-negotiation | Support |
| Port flow control | Support full duplex IEEE802.3x flow control Support Half-duplex back pressure flow control |
| Broadcast storm control | Support broadcast, multicast, DLF packet rate limit |
| Port Mirroring | Support |
| Port Isolation | Support |
| Port Self-loop Detection | Support |
| Link Aggregation | Supports up to 128 aggregation groups, each group supports up to 8 ports |
| Jumbo Frame | Jumbo packets up to 12K bytes |
| Redundant port | Support |
| MAC configuration | |
| MAC address table | 32K |
| MAC address table management | Support |
| Static MAC address | Support |
| MAC Address Binding | Support |
| MAC Address Filtering | Support |
| MAC Address Learning control | Control number of port-based MAC address learning |
| VLAN configuration | |
| Number of VLANs | 4K |
| Port-based VLAN | Support |
| 802.1q VLANs | Support |
| MAC-based VLAN | Support |
| IP-based VLAN | Support |
| Protocol-based VLAN | Support |
| Voice VLAN | Support |
| VLAN mapping | Support |
| QinQ | Support |
| Reliability Protocol | |
| Spanning Tree Protocol | Support STP/RSTP/MSTP |
| EAPS Protocol | Support |
| ERPS Protocol | Support G.8032/Y.1344 |
| LLDP | Support LLDP & LLDP-MED |
| UDLP Protocol | Fully compatible with CISCO's UDLD protocol |
| VLLP | Support, Use with VRRP routing |
| Routing | |
| ARP | Support static and dynamic ARP |
| Static routing | Support |
| VLAN interface | Support 32 VLAN interfaces |
| L3 routing protocol | |
| RIP | Support RIP v1/v2 |
| OSPF | Support OSPF v2 |
| Policy routing | Support |
| VRRP | Support |
| Multicast functions and protocols | |
| Static multicast MAC address | Support |
| IGMP SNOOPING | Support IGMP SNOOPING v1/v2/v3 |
| MVR | Support |
| GMRP | Support |
| ACL access control list | |
| ACL based on standard IP | Support |
| ACL based on extended IP | Support |
| ACL based on MAC IP | Support |
| ACL based on MAC ARP | Support |
| ACL port filtering | Support |
| ACL based on time | Support |
| QoS | |
| Number of port queues | 8 |
| Queue scheduling algorithms | Support WRR, RR, WDRR, SP |
| Classification based on port | Support |
| Classification based on 802.1p | Support |
| Classification based on DSCP | Support |
| Classification based on ACL | Support |
| QoS policy | Supports mapping of different data streams to different queues Support data stream to modify COS or DSCP value Support the speed limit of data stream Support data stream statistics Support data stream mirroring |
| DHCP | |
| DHCP Client | Support |
| DHCP Snooping | Support |
| DHCP Relay | Support |
| DHCP Server | Support |
| DHCP option 82 | Support |
| Security | |
| ACL | Support Standard IP / Extend IP / MAC IP / ARP |
| Security Features | Support MAC-based 802.1X authentication Support AAA/RADIUS authentication Support WEB/Telnet password protection |
| Self-protection | Support CPU Self-protection |
| Management | |
| CLI | Support CLI (Commend Line Interface) configuration mode |
| Console | Support Configuration via the console port |
| Telnet | Support Local/remote configuration via Telnet |
| WEB | Support Web management system |
| SNMP | Support System configuration with SNMP v1/v2c |
| User Management | Support Multi-user management |
| System Log | Support |
| Configuration File Download/Upload | Support Download/Upload configuration File via WEB/TFTP/USB |
| Upgrade Firmware | Support Upgrade Firmware via WEB/TFTP |
| Debug | |
| PING | Support |
| TRACEROUTE | Support |
| Telnet client | Support |
