Cudy GP1200 (AC1200)

GP1200 (AC1200)

69.71 azn

Cudy

GPON

WiFi5

Mesh

Dual band

2.4Ghz/5Ghz

1000 mb/s

GP1200 (AC1200)

Haqqında

CUDY GP1200 AC1200 Wi-Fi GPON Router 1.15 GHz Dual-Core CPU, Max 2.48 Gbps GPON / 1.25 Gbps EPON, 4-Stream Dual-Band Wi-Fi 5, 867 Mbps + 300 Mbps Wi-Fi, 1× SC/APC Slot, 4× Gigabit Ethernet Ports, OMCI/OAM/TR069/TR098/TR181, EasyMesh

Tip	GPON
WIFI	WiFi5
Mesh	Mesh
Genişlik	Dual band
Tezlik	2.4Ghz/5Ghz
Port sürəti	1000 mb/s

Ətraflı

GP1200 1.0
Chipset	RTL9607C
CPU Details	1.15 GHz Dual-Core
Flash/ROM	128 MB (1 Gbit) NAND
DDR/RAM	256 MB (2 Gbit) DDR3
Protocols	GPON (ITU G. 984 standard, Class B+) EPON (802.3ah)
Speed	GPON: 2.488 Gbps Downstream / 1.244 Gbps Upstream EPON: 1.25 Gbps Downstream / Upstream
Wavelength	TX: 1310 nm RX: 1490 nm
Max Transmission Distance	20 km
5 GHz Wi-Fi Speed	867 Mbps
2.4 GHz Wi-Fi Speed	300 Mbps
5 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
Wi-Fi Antennas	2× Fixed
5 GHz Antenna Gain Max	5dBi
2.4 GHz Antenna Gain Max	5dBi
Beamforming	True
Range Performance	Max: 170 m (558 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
Wall Performance	One wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'')
SC/APC Port	1
Gigabit RJ45 Ports	4
USB-A 2.0 Ports	Optional for ISP Order
LED	Power PON LOS Internet 2.4 GHz Wi-Fi 5 GHz Wi-Fi WPS LAN
Physical Buttons	Power On/Off Button Reset Button WPS Button Wi-Fi On/Off Button
Power Input	DC Jack
Power Methods	DC
DC	12V 1A
Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC
Environment	Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 95% non-condensing
FCC, CE
Installation	Desktop Wall-mount
Dimension	173×123.8×33 mm 6.81×4.87×1.3 inches
Product Weight	288 g (10.16 oz.)
GP1200 Power Adapter Ethernet Cable Installation Guide
Retail Package Dimension	304×268×54 mm 11.97×10.55×2.13 inches
Retail Package Weight	EU / US: 681 g (24.02 oz.)
Carton Net Weight	EU / US: 13.6 kg (29.98 lbs)
Carton Gross Weight	EU / US: 15.3 kg (33.73 lbs)
Units per Carton	20
Carton Dimension	55.6×55.5×32.5 cm 21.89×21.85×12.8 inches
GP1200 1.0
Wi-Fi Standards	Wi-Fi 5
Max Wi-Fi Modulation	256-QAM
Wi-Fi Efficiency	MU-MIMO
Wi-Fi Efficiency Note	MU-MIMO available on 5 GHz
Max Capacity	128
Recommended Client Upper Limit	50
Max Wi-Fi Channel Width	80 MHz
Wi-Fi Security	WPA-PSK (WPA/WPA2)
Guest Network	2.4 GHz, 5 GHz
WPS	true
Operation Modes	xPON Wi-FI Router
Mesh	EasyMesh R2
Mesh Backhaul	Wireless Backhaul Wired Backhaul
WAN Mode	DHCP Static IP PPPOE
QoS	4 Queues 802.1p Classification DSCP Traffic Shaping By MAC By IP By Port
DHCP	Address Reservation DHCP Client List Server
IP Versions	IPv4/IPv6
IPv6 Protocols	Dynamic (SLAAC/DHCPv6) Staic (Fixed IP)
IPTV/VLAN	Bridge Tag VLAN
TTL Customization	Extend Spoof Custom
IGMP	IGMP Proxy
Forwarding	Port Forwarding UPnP DMZ
Firewall	SPI Firewall
DNS Options	Manual DNS
Online Detection	true
All Devices Management	MAC Filter IP/MAC Binding
Content Management	Domain Filter IP Filter Port Filter
Local Control Method	Config Web Page
Remote Control Method	TR069/TR098/TR111/TR181
Firmware Upgrade	Local Update
Reliability	Backup and Restore
Languages	English Simplified Chinese Hindi Bengali French Portuguese Russian Urdu Indonesian German Arabic Spanish
