Cudy WR300 (N300)

WR300 (N300)

30.60 azn

Cudy

Mesh

WiFi4

100 mb/s

2.4Ghz

20+

WR300 (N300)

Haqqında

Cudy WR300 (N300) 4 Fast Ethernet portu olan WiFi marşrutlaşdırıcısı Cudy Mesh və yerli proqram nəzarəti ilə videonun rahat şəkildə oxudulmasına və maksimum 100 Mbps internetə çıxışa imkan verir. Router, Access Point, Range Extender, WISP, Cudy Mesh modlarını dəstəkləyir.

Mesh	Mesh
WIFI	WiFi4
Port sürəti	100 mb/s
Tezlik	2.4Ghz
Qoşulma sayı	20+

Ətraflı

WR300 1.0
Chipset	MT7628
CPU Details	580 MHz Single-Core, MIPS24KEC
Flash/ROM	8 MB (64 Mbit ) NOR
DDR/RAM	64 MB (512 Mbit) DDR2
2.4 GHz Wi-Fi Speed	300 Mbps
2.4 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
Wi-Fi Antennas	2× Fixed
FEM or PA/LNA	2.4 GHz: 2× Internal
Range Performance	Max: 130 m (427 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
Wall Performance	One wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 10 cm (4'')
10/100 Mbps RJ45 Ports	4
Ethernet Notes	1× WAN port, the rest are LAN ports
LED	System
Physical Buttons	WPS Button Reset Button
Power Input	DC Jack
Power Methods	DC
DC	5V 1A
Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC Output: 5V 1A DC
Environment	Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 95% non-condensing
FCC, CE
Installation	Desktop
Dimension	118×80×27.5 mm 4.65×3.15×1.08 inches
Product Weight	120 g (4.23 oz.)

Retail Package Weight	EU: 336 g (11.85 oz.)
Retail Package Dimension	176×140.5×56 mm 6.93×5.53×2.2 inches
Units per Carton	40
Carton Dimension	60×30×37.5 cm 23.62×11.81×14.76 inches
Carton Gross Weight	EU: 14.4 kg (31.75 lbs)
Carton Net Weight	EU: 13.4 kg (29.54 lbs)
WR300 1.0
Wi-Fi Standards	Wi-Fi 4
Max Wi-Fi Modulation	64-QAM
Max Capacity	64
Recommended Client Upper Limit	30
Max Wi-Fi Channel Width	40 MHz
Wi-Fi Security	WPA/WPA2/WPA3
Guest Network	2.4 GHz
WPS	True
Operation Modes	Wi-Fi Router Access Point Range Extender WISP Client
Mesh	Cudy Mesh
Mesh Backhaul	Wireless Backhaul Wired Backhaul
WAN Mode	DHCP Static IP PPPOE PPTP L2TP
Internet Failover Sequence	WAN WISP
QoS	Per-User Rate Limiting
DHCP	Address Reservation DHCP Client List Server
IP Versions	IPv4/IPv6
IPv6 Protocols	Relay Dynamic (SLAAC/DHCPv6) Staic (Fixed IP) Passthrough 464XLAT MAP-E DS-Lite
IPTV/VLAN	Bridge Tag VLAN
TTL Customization	Extend Spoof Custom
IGMP	IGMP Proxy IGMP Snooping
Forwarding	Port Forwarding Port Triggering UPnP DMZ
Firewall	SPI Firewall DoS Protection Block PING
Application Layer Gateway	IPSec Passthrough L2TP Passthrough PPTP Passthrough FTP Passthrough TFTP Passthrough H323 Passthrough SIP Passthrough RTSP Passthrough
VPN Client	Wireguard PPTP L2TP
VPN Performance	WireGuard Client (UL/DL): 49 / 43 Mbps WireGuard Server (UL/DL): 43.6 / 48 Mbps
DNS Options	DNS over TLS Manual DNS Rebind Protection Override Clients' DNS
DNS over TLS Providers	Cloudflare Google Quad9 Custom
Wake on LAN	True
Online Detection	True
All Devices Management	Wi-Fi Time Schedule MAC Filter IP/MAC Binding
Per-Devices Management	Intenent On/Off VPN On/Off Online Time Schedule Device Rename
Content Management	Domain Filter IP Filter
LED Control	ture
Local Control Method	Config Web Page App Control
Remote Control Method	Config Page via HTTPS TR069/TR098/TR111/TR181
Firmware Upgrade	Local Update
Reliability	Timed Reboot Backup and Restore
Diagnostic Tools	Diagnosis Ping Traceroute NSLookup System Log
Languages	English Bengali Catalan Czech German Greek Spanish French Hebrew Croatian Hungarian Italian Japanese Khmer Korean Dutch Norwegian Polish Portuguese Romanian Russian Slovak Swedish Thai Turkish Ukrainian Vietnamese Simplified Chinese Traditional Chinese
Panel	Internet Status Mesh Status Devices Management WAN Status LAN Status WISP Status Wi-Fi Status VPN Status DHCP Server Status System Version
Charts	Mesh Topology Internet Speed WISP Speed Wi-Fi Speed
