GNT-MP1420ES
195.69 azn
Genata
250 W
16 Port
PoE
100mb/s
Stokda yoxdur
Haqqında
GNT-MP1420ES16p 2Up-Link 2SFP 250m AI PoE SwitchGenata
| PoE gücü | 250 W |
| Port sayı | 16 Port |
| PoE | PoE |
| Port sürəti | 100mb/s |
Ətraflı
| Model | GNT-MP1420ES |
Ports | PoE (1~14):10/100Mbps PoE ports (RJ45) PoE (15~16):10/100Mbps PoE ports,Support bt 60W High Power LAN (17~18):10/100/1000Mbps uplink ports (RJ45) SFP (19~20):10/100/1000Mbps SFPport |
| Transmission Rate | 2000Mbps FullDuplex; 10 or 100Mbps Half Duplex |
Transmission Distance | Port1~15: 10/100Mbps 130meters; 10Mbps Auto-adaption 250meters Port16: 10/100Mbps 130meters |
Performance Specification | Bandwidth:11.2Gbps |
| Network Latency(1000Mbps): ≦16μs (use the 64bytepackage size) | |
| MAC address table: 8K | |
The FrameFilter & Transmission Rate: 14800pps the most for 10M port, 148800pps the most for 100M port;1488000pps the most for 1000M port | |
Networking Standard | IEEE 802.3i 10BASE-T/IEEE 802.3u100BASE-TX |
| IEEE 802.3ab 1000BASE-T | |
| IEEE 802.3x Flow Control | |
| IEEE 802.3af/at/bt Power over Ethernet | |
Power Support | Power Input:AC 90~240V Total≤240W AI Watchdog: Port 1~16 Power Output:PoE1~14 Port:1/2(+52V),3/6(GND)≤30W PoE15~16 Port:1245(+53V),3678(GND) Compatible1/2(+52V),3/6(GND)≤60W |
| Protection Level | Lightning Protection:6KV ESD Protection:8KV |
| Physical Specifications | Size(L*W*H): 270mm*170mm*45mm, Weight:1.75KG |
Working Environment | Operating Temperature: -30°C~60°C |
| Storage Temperature: -40°C~70°C | |
| Operating Humidity: 10%~90% Non-condensing | |
| Storage Humidity: 5%~90% Non-condensing | |
Certification | CE |
| FCC | |
| RoHS 2.0 | |
| Warranty | Whole Device:1 year |
| Package Content | AC Power Cable,User Manual |
