DS-7204HQHI-K1
221.02 azn
Stokda yoxdur
Haqqında
DS-7204HQHI-K1 4 AUDIO DIGITAL VIDEO RECORDER HIKVISION
| Növ | XVR |
| Kanal sayı | 4 kanal |
| Meqapixel | 4 MP |
| Max HDD sayı | 1 HDD |
| Max HDD həcmi | 10 TB |
Ətraflı
| DS-7204HQHI-K1 | |
Video compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Analog video input | 4-ch |
| BNC interface (1.0 Vp-p,75 Ω), supporting coaxitron connection | |
| HDTVI input | 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30,720p25 Note: The 3 MP signal input is only available for channel 1 of DS-7204HQHI-K1, for channel 1/2 of DS-7208HQHI-K1, and for channel 1/2/3/4 of DS-7216HQHI-K1. |
| AHD input | 4 MP,1080p25, 1080p30, 720p25, 720p30 |
| HDCVI input | 1080p25, 1080p30, 720p25, 720p30 |
| CVBS input | PAL/NTSC |
IP videoinput | 1-ch (up to 5-ch) |
| Up to 4 MP resolution | |
| Supports H.265+/H.265/H.264+/H.264 IP cameras | |
| Audio compression | G.711u |
| Audio input | 1-ch, RCA (2.0 Vp-p,1 KΩ) |
| CVBS output | 1-ch, BNC(1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC:704 × 480 |
HDMI/VGA output |
1-ch, 1920× 1080/60Hz, 1280× 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Encoding resolution | When 1080p Lite mode is not enabled: 4 MP lite/3 MP/1080p/720p/WD1/4CIF/VGA/CIF; When1080p Lite mode is enabled: 4 MP lite/3MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF |
Frame rate | Main stream: When 1080pLite mode not enabled: For 4 MP stream access:4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 3 MP streamaccess: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080pstream access: 1080p@15fps; 720p/VGA/WD1/4CIF/CIF@25fps(P)/30fps (N) For 720p streamaccess: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080pLite mode enabled: 4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) | |
| Video bit rate | 32 Kbps to 6 Mbps |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Audio bit rate | 64 Kbps |
| Dual stream | Support |
| Stream type | Video, Video& Audio |
Synchronous playback | 4-ch |
Remote connections | 32 |
Network protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP,SADP, NFS, iSCSI,UPnP™, HTTPS, ONVIF |
| SATA | 1 SATA interface |
| Capacity | Up to 10 TB capacity for each disk |
Two-way audio input | 1-ch, RCA (2.0 Vp-p,1 KΩ) (using the 1st audio input) |
| Network interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
| USB interface | 2 × USB 2.0 |
| Serial interface | RS-485 (half-duplex) |
| Power supply | 12 VDC |
| Consumption (without HDD) | ≤ 6 W |
| Working temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
| Working humidity | 10% to 90% |
Dimensions (W × D × H) | 315 × 242 × 45 mm(12.4 × 9.5 × 1.8 inch) |
Weight (without HDD) | ≤ 1.16 kg (2.6 lb) |
