DHI-NVR5464-EI
1322.05 azn
Stokda yoxdur
Haqqında
DAHUA DHI-NVR5464-EI 64CH NETWORK VIDEO RECORDER
| Növ | NVR |
| Kanal sayı | 64 kanal |
| Meqapixel | 12 MP |
| Max HDD sayı | 4 HDD |
| Max HDD həcmi | 16 TB |
Ətraflı
| Main Processor | Industrial-grade processor |
| Operating System | Embedded Linux |
| Operating Interface | Web, LocalGUI |
AI by Recorder | Face detection; face recognition; perimeter protection; SMD Plus |
AI by Camera | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map |
| AcuPick AI by Camera+ Recorder |
Max. 16-channel, 1 combined eventper channel/s |
| Perimeter Performance AI by Recorder (Number of Channels) |
4 channels, 10 IVS rulesfor each channel |
| Perimeter Performance of AI by Camera (Number of Channels) |
16 channels |
Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Recorder (Number of Channels) |
2 channels (up to 12 face images/s each channel) |
| Face Detection Performance of AI by Camera (Number of Channels) |
16 channels |
Face Database Capacity | Up to 20 face databases with 20,000 images,with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state canbe added to each faceimage. |
| Face Recognition Performance of AI by Recorder (Number of Channels) |
stream: 16 face images/s
stream: 12 face images/s |
| Face Recognition Performance of AI by Camera (Number of Channels) |
16 channels |
SMD Plus by Recorder | 8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera | 16 channels |
| ANPR by Camera (Number of Channels) |
8 channels |
| License Plate Database Capacity |
|
| Access Channel | 64 |
Network Bandwidth |
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AIenabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbpsoutgoing |
| Resolution | 32MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1;CIF; QCIF |
Decoding Capability | AIdisabled: 2-channel 32 MP@20 fps;2-channel 24 MP@20fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps AI enabled: 1-channel 32 MP@20 fps;1-channel 24 MP@20fps; 2-channel 16 MP@30 fps;4-channel 12 MP@30fps; 4-channel 8 MP@30 fps;8-channel 5 MP@30fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fps |
Video Output |
2 VGA,2 HDMI VGA:1920 × 1080, 1280 × 1024,1280 × 720 HDMI:3840 × 2160, 1920× 1080, 1280× 1024, 1280× 720 Heterogeneous video source output for HDMI1 and HDMI2 Simultaneous video source output for VGA1 and HDMI1 Simultaneous video source outputfor VGA2 and HDMI2 |
| Multi-screen Display | Main screen: 1/4/8/9/16/25/36/64 Sub screen: 1/4/8/9/16 |
| Third-party CameraAccess | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Samsung |
| Video Compression | Smart H.265+;H.265; Smart H.264+;H.264; MJPEG |
| Audio Compression | G.711a; G.711u; PCM; G726 |
Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP;IP Filter; PPPoE;FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P;Auto Registration; iSCSI |
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF 22.06(Profile T; ProfileS; Profile G); CGI; SDK |
| Browser | Chrome;IE;Safari;Edge;Firefox |
| Network Mode | Multi-address mode, load balance, fault tolerance and other network port binding modes |
| Storage | |
| Disk Group | YES |
| Alarm | |
| General Alarm | Motion detection; privacy masking; local alarm |
Anomaly Alarm | Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception |
Intelligent Alarm | Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicledensity; heat map |
Alarm Linkage | Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log,preset; email |
| Port | |
| Audio Input | 1-channel RCA |
| Audio Output | 2-channel RCA |
| Alarm Input | 16 channels |
| Alarm Output | 6 channels (1-channel 12 V 1 A output) |
HDD Interface | 4SATA ports, eachdisk can contain up to 16 TB. Thislimit varies depending on the environment temperature. |
| eSATA | 1 |
| RS-232 | 1 |
| RS-485 | 1 (half-duplex serial communication) |
| USB | 3(1 frontUSB 2.0 port,2 rear USB 3.0 ports) |
| HDMI | 2 |
| VGA | 2 |
| Network Port | 2 (10/100/1000 Mbps Ethernet port,RJ-45) |
| General | |
| Power Supply | 100–240 VAC,50-60 Hz |
| Power Consumption | Total outputof NVR is ≤ 13 W (without HDD) |
| Net Weight | 4.74 kg (10.45 lb) |
| Gross Weight | 6.11 kg (13.47 lb) |
Product Dimensions | 440.0 mm × 415.1mm x 70.0 mm (17.32" × 16.34" × 2.76") (W ×D × H) |
Packaging Dimensions | 530.0 mm × 500.0mm × 210.0 mm (20.87" × 19.69" × 8.27")(W × D × H) |
| Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 10%–93% (RH) |
| Installation | Rack or desktop |
Certifications | FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3- 2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021;EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014 |
