DS-2CD1T43G2-LIUF
169.01 azn
Haqqında
DS-2CD1T43G2-LIUF 4mm 4mp IR 50m LED 30m Hybrid Light Big Bullet IP KAMERA HIKVISION
| Növ | IP |
| Meqapixel | 4 MP |
| İşıqlandırma | LED |
| İşıqlandırma məsafəsi | 30 m |
| Mikrofon | Mic |
| Obyektiv | Sabit |
| Fokus | 4 |
| Qoruma | IP67 |
| Material | Metal |
Ətraflı
| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Max. Resolution | 2560 × 1440 |
| Min. Illumination | Color: 0.005 Lux @ (F1.6,AGC ON), B/W: 0 Lux withIR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360° |
| Lens | |
| Lens Type | Fixed focallens, 4 and 6 mm optional |
| Focal Length& FOV | 4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93° 6 mm, horizontal FOV 49°, vertical FOV 26°, diagonal FOV 57° |
| Iris Type | Fixed |
| Lens Mount | M12 |
| Aperture | F1.6 |
| DORI | |
| DORI | 4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m 6 mm, D: 128 m, O: 50 m, R: 25 m, I: 12 m |
| Illuminator | |
| Supplement LightRange | Up to 50 m |
| Smart Supplement Light | Yes |
| Supplement Light Type | IR, White Light |
| IR Wavelength | 850 nm |
| Video | |
Main Stream | 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 24 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 24 fps(1280 × 720, 640 × 480, 640 × 360) |
| H.265 Type | Main Profile |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile, Main Profile, HighProfile |
| Bit Rate Control | CBR, VBR |
| Region of Interest (ROI) | 1 fixed regionfor main stream |
| Audio | |
| Audio Bit Rate | 64 Kbps(G.711 ulaw)/64 Kbps(G.711 alaw) /16 Kbps(G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Audio Type | Mono sound |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz |
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/ G.726/MP2L2/PCM/AAC-LC |
| Network | |
| Web Browser | Plug-in required live view: IE 10, IE11, Local service: Chrome 57.0+, Firefox 52.0+ |
| Client | iVMS-4200, Hik-Connect |
| Simultaneous LiveView | Up to 6 channels |
Security | Password protection, complicated password, watermark, basicand digest authentication forHTTP, WSSE and digest authentication for Open Network Video Interface, securityaudit log, hostauthentication (MAC address) |
| API | Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)), ISAPI, SDK |
| Protocols | TCP/IP, ICMP, DHCP,DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6,UDP, QoS, FTP,SMTP |
| User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Image | |
| Day/Night Switch | Day, Night,Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Wide Dynamic Range(WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Privacy Mask | 4 programmable polygon privacy masks |
| Interface | |
| On-Board Storage | -F: Built-in memory card slot, support microSD/microSDHC/microSDXCcard, up to 512 GB |
| Built-in Microphone | Yes |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Reset Key | -F: Yes |
| Event | |
| Basic Event | Motion detection (support alarm triggering by specified targettypes (human and vehicle)), videotampering alarm, exception |
| Linkage | Upload to FTP/memory card (-F), sendemail, notify surveillance center, trigger recording (-F),trigger capture |
| General | |
Power | 12 VDC ± 25%, 0.5A, max. 6 W, Ø5.5 mm coaxial powerplug, reverse polarity protection, PoE: IEEE802.3af, Class 3, max. 7 W |
| Material | Metal & Plastic |
| Dimension | 83.7 mm × 80.7 mm × 205.6 mm (3.3" × 3.2" × 8.1") |
| Package Dimension | 260 mm × 125 mm × 125 mm (10.2" × 4.9" × 4.9") |
| With Package Weight | Approx. 635 g (1.4 lb.) |
| Weight | Approx. 580g (1.3 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less(non-condensing) |
Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less(non-condensing) |
| Language | English, Ukrainian |
| General Function | Heartbeat, anti-banding, mirror,password protection, password reset via email |
