DS-2CD1T23G0-I
132.02 azn
Haqqında
DS-2CD1T23G0-I 4mm 2mp IR 50m Big Bullet IP KAMERA HIKVISION
| Növ | IP |
| Meqapixel | 2 MP |
| İşıqlandırma məsafəsi | 50 m |
| Obyektiv | Sabit |
| Fokus | 4 |
| İşıqlandırma | İR |
| Qoruma | IP67 |
| Material | Metal |
Ətraflı
| Camera | |
| Image Sensor | 1/2.8″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.028Lux @ (F2.0,AGC ON), 0 Luxwith IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | Digital WDR |
| Day & Night | ICR Cut |
| Angle Adjustment | Pan: 0° to 360°, tilt:0° to 180°, rotate: 0° to 360° |
| Lens | |
| Lens Type& FOV | 4 mm, horizontal FOV 86°, vertical FOV 47°, diagonal FOV 103° 6mm, horizontal FOV 54°, vertical FOV 31°, diagonal FOV 63° |
| Aperture | F2.0 |
| Lens Mount | M12 |
| Illuminator | |
| IR Range | 50 m |
| Wavelength | 850 nm |
| Smart Supplement Light | Yes |
| Video | |
| Max. Resolution | 1920 × 1080 |
| Main Stream | 50Hz: 25fps(1920 × 1080,1280 × 960, 1280 × 720) 60Hz: 30fps(1920 × 1080, 1280 × 960, 1280× 720) |
| Sub Stream | 50Hz: 25fps(640 × 480,640 × 360, 320 × 240) 60Hz: 30fps(640 × 480,640 × 360, 320 × 240) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 8Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Stream Type | Main stream/Sub-stream |
| Region of Interest (ROI) | 1 fixed regionfor main streamand sub-stream |
| Network | |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (PROFILE S, PROFILE G),ISAPI, SDK |
| Protocols | TCP/IP, ICMP, HTTP,HTTPS, FTP, DHCP,DNS, RTP, RTSP,RTCP, NTP, IGMP,QoS, UDP |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
Security | Password protection, complicated password, HTTPS encryption, watermark, IP addressfilter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF,RTP/RTSP OVER HTTPS,Control Timeout Settings, Security Audit Log,TLS 1.2 |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | IE8+, Chrome31.0-44, Firefox30.0-51, Safari8.0+ |
| Image | |
| Day/Night Switch | Day, Night,Auto, Schedule |
| Image Enhancement | BLC, HLC,3D DNR |
| Image Settings | Rotate mode,saturation, brightness, contrast, sharpness, AGC, whitebalance adjustable by client software or web browser |
| SNR | > 50 dB |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Intelligent (Traditional Algorithm) | |
| Basic Event | Motion detection, video tampering alarm,exception (illegal login) |
| General | |
| Firmware Version | V5.5.84 |
| Linkage Method | Upload to FTP, notifysurveillance center, send email, triggercapture |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less(non-condensing) |
Startup and Operating Conditions | -30 °C to 60 °C (-22°F to 140 °F). Humidity 95% or less(non-condensing) |
| Power Supply | 12 VDC ± 25%, PoE: 802.3af, Type 1 Class3, reverse polarity protection |
Power Consumption and Current | 12 VDC, 0.40 A, max. 4.8 W PoE (802.3af, 36 V to 57 V), 0.20A to 0.10 A, max.6 W |
| Power Interface | Φ5.5 mm coaxial powerplug |
| Material | Front cover& bracket: metal Back cover& sun shield: plastic |
| Camera Dimension | 71.67 × 92.87 × 221.49 mm (2.82" × 3.65" × 8.72") |
| Package Dimension | 234 × 120 × 117 mm (9.21" × 4.72" × 4.61") |
| Camera Weight | 540 g (1.19 lb.) |
| With PackageWeight | 810 g (1.79 lb.) |
| Approval | |
| Protection | Ingression protection: IP67 (IEC 60529-2013) |
| EMC | FCC (47 CFR Part15, Subpart B); CE-EMC (EN 55032: 2015,EN 61000-3-2: 2014,EN 61000-3-3: 2013,EN 50130-4: 2011 +A1:2014); IC (ICES-003: Issue 6, 2016) |
| Safety | UL (UL 60950-1); CB (IEC60950-1:2005 + Am 1:2009+ Am 2:2013); CE-LVD (EN 60950- 1:2005 + Am 1:2009+ Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); |
