DS-2CE16D0T-LPFS
DS-2CE16D0T-LPFS

52.99 azn

Hikvision
Analoq
2 MP
LED
25 m
Mic
Sabit
3.6
IP67
Plastik

Stokda yoxdur

DS-2CE16D0T-LPFS

Stokda yoxdur
DS-2CE16D0T-LPFS

Haqqında

DS-2CE16D0T-LPFS 3.6mm 2mp Smart IR 25m LED 20m HD MINI BULLET KAMERA HIKVISION

Növ Analoq
Meqapixel 2 MP
İşıqlandırma LED
İşıqlandırma məsafəsi 25 m
Mikrofon Mic
Obyektiv Sabit
Fokus 3.6
Qoruma IP67
Material Plastik

Ətraflı

  • Specification
Camera
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter TimePAL: 1/25 sto 1/50, 000 s; NTSC:1/30 s to 1/50, 000s
Day & NightICR
Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
Signal SystemPAL/NTSC
Lens
Lens Type2.8 mm, 3.6 mm fixedfocal lens
Focal Length& FOV

2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°

3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°

Lens MountM12
Illuminator
Supplement Light TypeWhite Light,IR
Supplement LightRange

IR : Up to 25 m

White Light : Up to 20 m

Image SettingsBrightness, Sharpness, Smart IR





Frame Rate

TVI: 1080P @ 30 fps, 1080P @ 25 fps AHD: 1080P @ 30 fps, 1080P @ 25 fps CVI: 1080P @ 30 fps, 1080P @ 25 fps

CVBS: PAL/NTSC

Day/Night ModeAuto/Color/BW (Blackand White)
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementDWDR/BLC/HLC/Global
White BalanceAuto/Manual
AGCYes
Interface
Video OutputSwitchable TVI/AHD/CVI/CVBS
Built-in MicrophoneYes
General
MaterialPlastic
Dimension138.8 mm × 60.9 mm × 57.9mm (5.47" × 2.4 "× 2.3")
WeightApprox. 155 g(0.34 lb.)
Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
CommunicationHIKVISION-C
LanguageEnglish



Power Supply

12 VDC ± 25%

*You are recommended to use one power adapter to supply the power for one camera.

ConsumptionMax. 3.3 W
Approval
ProtectionIP67
