XVR301-16F
162.84 azn
Uniview
XVR
16 kanal
2 MP
1 HDD
6 TB
Haqqında
XVR UNIVIEW XVR301-16F 16CH DIGITAL VIDEO RECORDER
Növ | XVR |
Kanal sayı | 16 kanal |
Meqapixel | 2 MP |
Max HDD sayı | 1 HDD |
Max HDD həcmi | 6 TB |
Ətraflı
Model | XVR301-16F | |
Video/Audio Input | ||
Analog Video Input | 16-ch, BNC | |
IP Video Input | 2-ch(only IP up to 18ch), each channel up to 8MP | |
Supported Analog Camera Types | Support AHD input: 1080P@30fps 720P@30fps Support TVI input: 1080P@30fps 720P@30fps Support CVI input: 1080P@30fps 720P@30fps Support CVBS input | |
Audio Compression | G.711U | |
Video/Audio Output | ||
VGA Output | 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | |
HDMI Output | 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | |
Synchronous Playback | HD:16-ch SD:16-ch | |
Live view display | HDMI/VGA: 1/4/6/8/9/16/25 | |
Snapshot | ||
FTP/Schedule/Event Snapshot | Schedule snapshot is not supported 16-ch snapshot, up to 704*576 resolution | |
Network | ||
Incoming Bandwidth | 24Mbps (Up to 56Mbps after all analog channel conversion) | |
Outgoing Bandwidth | 64Mbps | |
Remote Users | 128 | |
Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP | |
Browser | IE(IE10/11) for Windows Firefox (version 52.0 and above) for Windows Chrome(version 45 and above) for Windows Edge(version 79 and above) for Windows | |
Encoding | ||
Recording Resolution | 1080P Lite/720P/D1 | |
Recording Frame Rate | Main stream | Sub stream |
1080P Lite@12fps | D1@12fps | |
720P@15fps | D1@15fps | |
Audio Sample Rate | 8KHz,16 bit per channel | |
Audio Bit Rate | 64Kbps per channel | |
Decoding | ||
Capability | Analog:16x 1080P Lite@12, 16x 720P@15 IP: 1 x 8MP@30, 2 x 4MP@30, 4 x 1080P@30, 8 x 720P@30,16 x D1@30 | |
Hard Disk | ||
SATA | 1 SATA interface | |
Capacity | Up to 6TB for each HDD | |
Smart Alarm | ||
VCA Detection | Ultra Motion Detection(UMD) for analog:8-ch | |
VCA Search | Behavior Search | |
General Alarm | ||
General Alarm | Motion detection | |
Alert Alarm | IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | |
External Interface | ||
Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface | |
USB Interface | Rear panel: 2 x USB2.0 | |
General | ||
Power Supply | 12V DC Power Consumption: ≤ 10 W( without HDD ) | |
Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) | |
Dimensions(W×D×H) | 253mm × 212mm × 42mm (10.0" × 8.4" × 1.7") | |
Weight ( without HDD ) | ≤0.85 Kg ( 1.87lb ) | |
Certification | ||
Certification | UL/CE/FCC /RoHS /WEEE |
