SD49225DB-HNY
SD49225DB-HNY

948.69 azn

Dahua
IP
2 MP
PTZ
2.7 - 13.5
İR
100m
IP66
Metal

Stokda yoxdur

SD49225DB-HNY

Stokda yoxdur
SD49225DB-HNY

Haqqında

DAHUA SD49225DB-HNY 2MP 25x NETWORK PTZ KAMERA

Növ IP
Meqapixel 2 MP
Obyektiv PTZ
Fokus 2.7 - 13.5
İşıqlandırma İR
İşıqlandırma məsafəsi 100m
Qoruma IP66
Material Metal

Ətraflı

CameraDatasheet
Image Sensor1/2.8" CMOS
Pixel2 MP
Max. Resolution1920 (H) × 1080 (V)
ROM128 MB
RAM256 MB
Electronic Shutter Speed1/1 s–1/30,000 s
Scanning SystemProgressive
Min. IlluminationColor: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux (IR light on)
Illumination Distance100 m (328.08 ft) (IR)
Illuminator On/Off ControlZoom Prio; Manual; Smart IR
Illuminator Number3 (IR)
Lens
Focal Length4.8 mm–120 mm
Max. ApertureF1.6–F3.5
Field of ViewH: 58.5°–2.8°; V: 33.2°–1.5°; D: 67.5°–3.2
Optical Zoom25x
Focus ControlAuto; semi-auto; manual
Close Focus Distance0.1 m–1.5 m (0.33 ft–4.92 ft)
Iris ControlAuto
DORI DistanceDetectObserveRecognizeIdentify
1,613 m (5,291.99 ft)646 m (2,119.42 ft)323 m (1,059.71 ft)161 m (528.22 ft)
PTZ
Pan/Tilt RangePan: 0° to 360° endless
Tilt: –15° to +90°, auto flip 180°
Manual Control SpeedPan: 0.1°/s–80°/s
Tilt: 0.1°/s–80°/s
Preset SpeedPan: 80°/s; Tilt: 80°/s
Preset300
Tour8 (up to 32 presets per tour)
Pattern5
Scan5
Power-off MemoryYes
Idle MotionPreset;Pattern;Tour;Scan
PTZ ProtocolDH-SD
Pelco-P/D (Auto recognition)
Intelligence
IVS (Perimeter Protection)Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification
Face DetectionSupports face detection, capturing pictures, and face enhancement
SMDYes
Video
Video CompressionSmart H.265+;H.265;Smart H.264+;H.264;H.264B;MJPEG(Sub Stream)
Streaming Capability3 streams
Resolution1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Video Frame RateMain stream: 1080p/960p/720p@(1–25/30 fps)
Sub stream 1: D1/VGA/CIF@(1–25/30 fps)
Sub stream 2: 1080p/960p/720p@(1–25/30 fps)
Bit Rate ControlCBR/VBR
Video Bit RateH.264: 1792 kbps–8192 kbps
H.265: 512 kbps–5632 kbps
Day/NightAuto (ICR)/Color/B/W
BLCYes
WDR120 dB
HLCYes
White BalanceAuto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp
Gain ControlAuto; manual
Noise Reduction2D NR; 3D NR
Motion DetectionYes
Region of Interest (RoI)Yes
Image StabilizationElectronic (EIS)
DefogElectronic
Digital Zoom16×
Image Rotation180°
Privacy MaskingUp to 24 areas can be set, with up to 8 areas in the same view
S/N Ratio≥ 55 dB
Audio
Audio CompressionG.711a; G.711Mu; G.722.1; G.726; MPEG2-Layer2; G.729
Network
Network PortRJ-45 (10/100 Base-T)
Network Protocol

HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;

802.1x;SSL;Qos;FTP;UPnP;ICMP;SNMP;SNMPv1/v2c/v3(MIB-2);IGMP;ARP;RTCP;RTP;PPPoE;IP Filter;RTMP;Bonjour;TCP;SMB;NFS

InteroperabilityCGI; Dahua SDK; API; SDK; ONVIF (Profle S&G&T)
Streaming MethodUnicast/Multicast
User/Host20 (total bandwidth: 64 M)
StorageFTP; Micro SD card (512 GB); NAS
BrowserIE 7 and later versions
Chrome
Firefox
Safari
Management SoftwareDMSS; DSS Pro
Mobile ClientiOS; Android; iPhone; iPad
Certification
CertificationsCE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4- 2014
Port
Audio Input1 channel (LINE IN, bare wire)
Audio Output1 channel (LINE OUT,bare wire)
Alarm LinkageCapture; preset; tour; pattern; recording; alarm digital input; audio; send email
Alarm Event

Motion/Tampering detection; audio detection; network disconnection detection;

IP conflict detection; memory card state detection; memory space detection;

 power exception detection

Alarm I/O2/1
Audio I/O1/1
Power
Power Supply12 VDC/3 A (± 10%)
PoE (802.3at)
Power ConsumptionBasic: 12 W
Max.: 20 W (IR light)
Environment
Operating Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity≤95%
ProtectionIP66, TVS 6000 V lightning proof; surge protection; voltage transient protection
Structure
Product Dimensions270.4 mm × Φ160.0 mm (10.65" × Φ6.30")
Net Weight2.4 kg (5.29 lb)
Gross Weight3.9 kg (8.60 lb)

948.69 azn

Dahua
IP
2 MP
PTZ
2.7 - 13.5
İR
100m
IP66
Metal

Stokda yoxdur
