NVR5232-4KS2
NVR5232-4KS2

765.08 azn

Dahua
NVR
32 kanal
8 MP
2 HDD
10 TB

Stokda yoxdur

Səbətə at AZN

NVR5232-4KS2

Stokda yoxdur
NVR5232-4KS2

Haqqında

Dahua NVR5232-4KS2 WizSense 32 kanal NVR; 2x10TB HDD; 8×1080p@30 fps;14 kanal uz tanima; 20 kanal perimetr protection; 32 kanal SMD Plus; Bandwidth 320 Mbps;

Növ NVR
Kanal sayı 32 kanal
Meqapixel 8 MP
Max HDD sayı 2 HDD
Max HDD həcmi 10 TB

Ətraflı

System
Main ProcessorIndustrial embedded micro-processor
Operating SystemEmbedded Linux
Operation InterfaceWeb; local GUI
Perimeter Protection by Camera
Performance20 channels
AI SearchSearch for pictures by channel, time and event type
Face Recognition by Camera
Performance14 channels
Face Attributes6 attributes: Gender; age; glasses; expression; mouth mask; beard
AI SearchSearch for pictures by channel, time and face attributes
SMD Plus by Camera
Performance32 channels
AI SearchSearch by target classification (human, vehicle)
Video Metadata by Camera
Performance16 channels
Human BodyTop; top color; bottom; bottom color; hat; bag; gender; age; umbrella
VehiclePlate No.; type; color; vehicle type; logo; plate color; ornament; calling; seatbelt; region
Non-motor VehicleType; color; number of passengers; helmet
AI SearchSupports searching for target video by metadata
ANPR by Camera
Performance4 channels
Stereo Analysis by Camera
Performance8/16/16 channels
AI SearchSearch by target classification (fall detection; people approach detection; people No. exception detection; people staying detection; violence detection)
Video
Access Channel8/16/32
Network Bandwidth320 Mbps for access, 320 Mbps for storage and 320 Mbps for forwarding
Resolution12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1, and more
Decoding Capability16-channel@1080P (30 fps)
Video OutputHDMI1: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720
VGA1: 1920 × 1080; 1280 × 1024; 1280 × 720
Multi-screen Display32-channel: 1/4/8/9/16/25/36
Third Party Camera AccessPanasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and more
Compression
VideoSmart H.265+; Smart H.264+; H.265; H.264; MJPEG
AudioPCM; G.711A; G.711U; G.726
Network
Network ProtocolHTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, and more.) ; P2P
Mobile Phone AccessAndroid; iOS
InteroperabilityONVIF (profile T/S/G); CGI; SDK
BrowserChrome; IE9 or later; Firefox
Record Playback
Multi-channel Playback1/4/9/16
Record ModeManual; schedule (general; MD; alarm; MD & alarm; intelligent; POS)
Storage MethodLocal HDD and network
BackupUSB device
Playback Function1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
2. Full screen; backup (cut/file) ; partially enlarge; audio on/off
Storage
Disk GroupYes
Alarm
General AlarmMotion detection; privacy masking; video loss; local alarm; PIR alarm; IPC alarm
Anomaly AlarmCamera offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly
Intelligent Alarm

Perimeter protection; face detection; face recognition; SMD; video metadata (human; motor-vehicle; non-motor vehicle) ; ANPR; people counting; stereo analysis; crowd distribution;

heat map

Alarm LinkageRecord; snapshot; IPC external alarm output; buzzer; log; preset; email
External Port
Audio Input1 channel, RCA connector
Audio Output1 channel, RCA connector, which supports voice intercom output
HDD2 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
Alarm Input4 channels
Alarm Output2 channels
RS-2321 channel, used to debug and pass through serial data
RS-4851 channel, used to control PTZ, and it supports multiple protocols
USB1 front USB 2.0 port, 1 rear USB 3.0 port
HDMI1
VGA1
Network1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet port
General Parameter
Power Supply12V/4A DC
Power Consumption< 9.5W (without HDD)
Net Weight1.6 kg (3.5 lb) (without HDD)
Gross Weight3.2 kg (7.1 lb) (without HDD)
Product Dimensions375.0 mm × 282.4 mm × 53.0 mm (14.8" × 11.1" × 2.1")
Package Dimensions429 mm × 137 mm × 360 mm (16.9" × 14.2" × 5.4")
Operating Temperature–10°C to +55°C (+14°F to +131°F)
Storage Temperature0°C to +40°C (+32°F to +104°F)
Operating Humidity10%–93% (RH)
Storage Humidity30%–85% (RH)
Operating Altitude3,000 m (9,843 ft)
CertificationsCE: EN55032; EN55024; EN50130-4; EN60950-1
FCC: Part 15 Subpart B; ANSI C63.4-2014
UL: UL 60950-1
