NVR1104HS-S3/H
103.29 azn
Dahua
NVR
4 kanal
8 MP
1 HDD
8 TB
Haqqında
Dahua NVR1104HS-S3/H WizSense 4 kanal NVR; 8TB HDD; 4×1080p@30 fps;
| Növ | NVR |
| Kanal sayı | 4 kanal |
| Meqapixel | 8 MP |
| Max HDD sayı | 1 HDD |
| Max HDD həcmi | 8 TB |
Ətraflı
| Model | NVR1104HS-S3/H |
| System | |
| Main processor | Built-in industrial grade processor |
| operating system | Embedded Linux OS |
| Operating interface | Internet / work in local graphical interface |
| Video | |
| Access channel | 4 channels |
| Network Bandwidth | 80 Mbit/s access, 80 Mbit/s storage and 60 Mbit/s forwarding |
| Permission | 8 MP; 5 MP; 4 MP; 3 MP; 1080p; 720p; D1; CIF |
| Decoding capability | 1-channel 8 MP (30 fps) or 1-channel 5 MP (30 fps) or 2-channel 4 MP (30 fps) or 2 channels 3 MP (30 fps) or 4 channels 1080p (30fps) |
| Video output | 1 simultaneous VGA / 1 HDMI video output, maximum resolution 1080p |
| Multi-screen display | 14 |
| Access to third party cameras | Onvif, RTSP |
| Compression | |
| Video | Smart H.265+ / H.265 / Smart H.264+ / H.264 |
| Audio | PCM/G711A/G711U/G726/AAC |
| Net | |
| Network protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; P2P |
| Mobile phone access | iDMSS (iOS); gDMSS (Android) |
| Access standard | ONVIF (profile T / profile S / profile G); CGI; SDK |
| Browser | Chrome; IE9 or higher; Fire Fox |
| Playing a recording | |
| Multi-channel playback | Up to 4 channels |
| Recording Mode | Recording Mode Priority: Manual Recording > Alarm Recording > Motion Detection Recording > Time Recording |
| Storage | Local hard drive and network |
| Backup | USB device |
| Playback function | 1.Play, Pause, Stop, Fast Forward, Fast Rewind, Rewind, Play Frame by Frame 2.Full Screen, Backup (Cut/File), Partial Zoom, Sound On/Off |
| Anxiety | |
| General alarm | Motion Detection, Privacy Masking, Video Loss, PIR Alarm, IPC Alarm |
| Abnormal Alarm | Interface Device Goes Down, Storage Error, Storage Full, IP Address Conflict, MAC Address Conflict, Login Blocked, Network Security Anomaly |
| Link to Anxiety | Video, Snapshot, Log, Preset, Tour |
| External port | |
| HDD | 1 SATA 2.0 port, up to 8 TB per hard drive. The maximum capacity of a hard drive depends on the ambient temperature. |
| USB | 1 USB 2.0 front, 1 USB 2.0 rear |
| HDMI | 1 |
| VGA | 1 |
| RCA input | 1 |
| RCA output | 1 |
| Anxiety | No |
| Net | 1 RJ–45 port (10/100 Mbps), 4 RJ–45 ports with PoE (10/100 Mbps) |
| Certificates | |
| Certificates | CE/FCC |
| Environment | |
| Operating temperature | -10°C to 45°C (+34°F to +113°F) |
| Storage temperature | 0°C to 40°C (+32°F to +104°F) |
| Operating humidity | 10%~93% |
| Storage Humidity | 30%~85% |
| Electrical properties | |
| Power supply | DC48V/53V, 1.25A/1.22A |
| Power consumption | NVR total power ≤ 10W (without HDD) Total PoE output power is 36W, single port maximum output power is 25.5W. |
| General information | |
| Mounting type | Desktop |
| Color | Black |
| Working height | 3000 m (9843 ft) |
| Dimensions | 260 mm × 225 mm × 47.6 mm |
| Net weight | 0.84 kg (1.85 lb) |
| Gross weight | 1.86 kg (4.10 lb) |
