M3000 (3-Pack)

M3000 (3-Pack)

Haqqında

Cudy M3000(3-Pack) AX3000 Wi-Fi 6 Mesh 2.5G Solution, 1.3 GHz Dual-Core CPU, 4-Stream Dual-Band Wi-Fi 6, 2402 Mbps + 574 Mbps Wi-Fi, 200 Connected Devices, Fast Roaming, Cudy Mesh, VPN Server and Client, Multi-Band Simultaneous Backhaul, Cudy App, Cloud Control

Qoşulma sayı 250+
WIFI WiFi6
Genişlik Dual band
Mesh Mesh
Tezlik 2.4Ghz/5Ghz

Ətraflı

M3000 1.0
ChipsetMT7981
CPU Details1.3 GHz Dual-Core, ARM Cortex-A53
Flash/ROM128 MB (1 Gbit) NAND
DDR/RAM256 MB (2 Gbit) DDR3
5 GHz Wi-Fi Speed2402 Mbps
2.4 GHz Wi-Fi Speed574 Mbps
5 GHz Wi-Fi Streams2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams2T2R (2×2 MIMO)
Wi-Fi Antennas5× Internal
5 GHz Antenna Gain Max5.1dBi
2.4 GHz Antenna Gain Max4.2dBi
FEM or PA/LNA
  • 5 GHz: 3× Internal
  • 2.4 GHz: 2× Internal
BeamformingTrue
Range PerformanceMax: 220 m (722 ft)
Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
Wall PerformanceTwo wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'')
Multi-Pack Indoor Coverage2 Pack: 400 m² (4300 sq ft)
3 Pack: 600 m² (6500 sq ft)
Applied to wireless backhaul situation. Place in the center of each floor, with a maximum of three obstacles to each room.
2.5G RJ45 Ports1
Gigabit RJ45 Ports1
Ethernet NotesThe 2.5G port is WAN port, the Gigabit port is LAN port
LED
  • System
  • Speed/Link/ACT of Ethernet Port
Physical Buttons
  • WPS Button
  • Reset Button
Power InputDC Jack
Power MethodsDC
DC12V 1A
Power AdapterInput: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC
Environment
  • Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
  • Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
  • Humidity: 10% ~ 90% non-condensing
  • Storage Humidity: 5% ~ 95% non-condensing
FCC, CE
InstallationDesktop
DimensionΦ110×154.5 mm
Φ4.33×6.08 inches
Product Weight360 g (12.7 oz.)

Retail Package Weight
  • 1-Pack | EU / US: 680 g (23.99 oz.)
  • 3-Pack | EU / US: 1500 g (52.91 oz.)
  • 2-Pack | EU / US: 1100 g (38.8 oz.)
  • 3-Pack | EU / US: 1827 g (64.45 oz.)
Retail Package Dimension
  • 1-Pack:
    145×130×265 mm
    5.71×5.12×10.43 inches
  • 2-Pack:
    330×130×265 mm
    12.99×5.12×10.43 inches
  • 3-Pack:
    380×130×265 mm
    14.96×5.12×10.43 inches
Units per Carton
  • 1-Pack: 16
  • 2-Pack: 8
  • 3-Pack: 4
Carton Dimension
  • 1-Pack: 57×56×26 cm
    22.44×22.05×10.24 inches
  • 2-Pack: 55×54.5×35.3 cm
    21.65×21.46×13.9 inches
  • 3-Pack: 53.6×40×28.7 cm
    21.1×15.75×11.3 inches
Carton Gross Weight
  • 1-Pack | EU / US: 12.2 kg (26.9 lbs)
  • 3-Pack | EU / US: 9.6 kg (21.16 lbs)
  • 2-Pack | EU / US: 12 kg (26.46 lbs)
  • 3-Pack | EU / US: 8.2 kg (18.08 lbs)
Carton Net Weight
  • 1-Pack | EU / US: 10.9 kg (24.03 lbs)
  • 3-Pack | EU / US: 8.5 kg (18.74 lbs)
  • 2-Pack | EU / US: 11.5 kg (25.35 lbs)
  • 3-Pack | EU / US: 7.3 kg (16.09 lbs)
M3000 1.0
Wi-Fi StandardsWi-Fi 6
Max Wi-Fi Modulation1024-QAM
Wi-Fi Efficiency
  • OFDMA
  • MU-MIMO
  • BSS Color
Max Capacity512
Recommended Client Upper Limit200
Max Wi-Fi Channel Width160 MHz
Wi-Fi SecurityWPA/WPA2/WPA3
Guest Network2.4 GHz, 5 GHz
WPSTrue
Operation Modes
  • Wi-Fi Router
  • Access Point
  • Range Extender
  • WISP
  • Client
MeshCudy Mesh
Mesh Backhaul
  • Wireless Backhaul
  • Wired Backhaul
Multi-Band Backhaultrue
WAN Mode
  • DHCP
  • Static IP
  • PPPOE
  • PPTP
  • L2TP
Internet Failover Sequence
  • WAN
  • WISP
QoSPer-User Rate Limiting
DHCP
  • Address Reservation
  • DHCP Client List
  • Server
IP VersionsIPv4/IPv6
IPv6 Protocols
  • Relay
  • Dynamic (SLAAC/DHCPv6)
  • Staic (Fixed IP)
  • Passthrough
  • 464XLAT
  • MAP-E
  • DS-Lite
IPTV/VLAN
  • Bridge
  • Tag VLAN
TTL Customization
  • Extend
  • Spoof
  • Custom
IGMP
  • IGMP Proxy
  • IGMP Snooping
Forwarding
  • Port Forwarding
  • Port Triggering
  • UPnP
  • DMZ
Firewall
  • SPI Firewall
  • DoS Protection
  • Block PING
Application Layer Gateway
  • IPSec Passthrough
  • L2TP Passthrough
  • PPTP Passthrough
  • FTP Passthrough
  • TFTP Passthrough
  • H323 Passthrough
  • SIP Passthrough
  • RTSP Passthrough
VPN Server
  • WireGuard
  • OpenVPN
  • IPsec
  • Zerotier
  • PPTP
  • L2TP
VPN Client
  • WireGuard
  • OpenVPN
  • IPsec
  • Zerotier
  • PPTP
  • L2TP
DNS Options
  • DNS over TLS
  • Manual DNS
  • Rebind Protection
  • Override Clients' DNS
DNS over TLS Providers
  • Cloudflare
  • Google
  • Quad9
  • Custom
Wake on LANTrue
Online DetectionTrue
All Devices Management
  • Wi-Fi Time Schedule
  • MAC Filter
  • IP/MAC Binding
Per-Devices Management
  • Intenent On/Off
  • VPN On/Off
  • Online Time Schedule
  • Device Rename
Content Management
  • Domain Filter
  • IP Filter
LED Controlture
Local Control Method
  • Config Web Page
  • App Control
Remote Control Method
  • Config Page via HTTPS
  • App Control
  • TR069/TR098/TR111/TR181
Firmware Upgrade
  • Local Update
  • App (Over the Air)
  • Online Update
Reliability
  • Timed Reboot
  • Backup and Restore
Diagnostic Tools
  • Diagnosis
  • Ping
  • Traceroute
  • NSLookup
  • System Log
Languages
  • English
  • Bengali
  • Catalan
  • Czech
  • German
  • Greek
  • Spanish
  • French
  • Hebrew
  • Croatian
  • Hungarian
  • Italian
  • Japanese
  • Khmer
  • Korean
  • Dutch
  • Norwegian
  • Polish
  • Portuguese
  • Romanian
  • Russian
  • Slovak
  • Swedish
  • Thai
  • Turkish
  • Ukrainian
  • Vietnamese
  • Simplified Chinese
  • Traditional Chinese
Panel
  • Internet Status
  • Mesh Status
  • Devices Management
  • WAN Status
  • LAN Status
  • WISP Status
  • Wi-Fi Status
  • VPN Status
  • DHCP Server Status
  • System Version
Charts
  • Mesh Topology
  • Internet Speed
  • WISP Speed
  • Wi-Fi Speed
