IPC-HFW2239SP-SA-LED-S2
IPC-HFW2239SP-SA-LED-S2

221.02 azn

Dahua
IP
2 MP
LED
30 m
Mic
Sabit
3.6
IP67
Metal
221.02

1

Səbətə at AZN

IPC-HFW2239SP-SA-LED-S2

IPC-HFW2239SP-SA-LED-S2

Haqqında

DAHUA IPC-HFW2239SP-SA-LED-S2 2MP 3.6MM FULL-COLOR NETWORK KAMERA

Növ IP
Meqapixel 2 MP
İşıqlandırma LED
İşıqlandırma məsafəsi 30 m
Mikrofon Mic
Obyektiv Sabit
Fokus 3.6
Qoruma IP67
Material Metal

Ətraflı

Camera
Image Sensor1/2.8" CMOS
Max. Resolution1920 (H) × 1080 (V)
ROM128 MB
RAM128 MB
Scanning SystemProgressive
Electronic Shutter SpeedAuto/Manual 1/3 s–1/100,000 s
Minimum Illumination

0.0017 lux@F1.0 (Color, 30 IRE)

0.0002 lux@F1.0 (B/W, 30 IRE)

0 lux (Illuminator on)

S/N Ratio> 56 dB
Illumination Distance30 m (98.4 ft)(Warm light)
Illuminator On/Off ControlAuto; Manual
Illuminator Number1 (Warm light)
Pan/Tilt/Rotation Range

Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°

Lens
Lens TypeFixed-focal
Mount TypeM12
Focal Length2.8 mm; 3.6 mm
Max. ApertureF1.0
Field of View

2.8 mm: H: 107°; V: 55°; D: 127°

3.6 mm: H: 91°; V: 47°; D: 109°

Iris TypeFixed
Close Focus Distance

2.8 mm: 0.9 m (3.0 ft)

3.6 mm: 1.3 m (4.3 ft)

DORI DistanceLensDetectObserveRecognizeIdentify
2.8 mm

46.5 m

(152.26 ft)

18.6 m

(61.02 ft)

9.3 m

(30.51 ft)

4.6 m

(15.09 ft)

3.6 mm

53.7 m

(176.18 ft)

21.5 m

(70.54 ft)

10.7 m

(35.10 ft)

5.4 m

(17.72 ft)

Smart event
IVSTripwire; intrusion
Video
Video CompressionH.265; H.264; H.264B; MJPEG (only supported by the sub stream)
Smart CodecSmart H.265+; Smart H.264+
Video Frame Rate

Main stream:

1920 × 1080 (1 fps-25/30 fps)

Sub stream:

704 × 576 (1 fps-25 fps)

704 × 480 (1 fps-30 fps)

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Stream Capability2 streams
Resolution1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 ×720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate ControlCBR; VBR
Video Bit RateH.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/NightColor/B/W
BLCYes
HLCYes
WDR120 dB
White BalanceAuto; natural; street lamp; outdoor; manual; regional custom
Gain ControlAuto; Manual
Noise Reduction3D NR
Motion DetectionOFF/ON (4 areas, rectangular)
Region of Interest(RoI)Yes (4 areas)
Smart IlluminationYes
Image Rotation0°/90°/180°/270° (Supports 90°/270° with 1080p resolution and lower)
MirrorYes
Privacy Masking4 areas
Audio
Built-in MICYes
Audio CompressionG.711A; G.711Mu; G.726
Alarm
Alarm EventNo SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; audio detection; safety exception
Network
NetworkRJ-45 (10/100 Base-T)
SDK and APIYes
Cyber SecurityVideo encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
ProtocolIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
InteroperabilityONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host20 (Total bandwidth: 72 M.)
StorageFTP; Micro SD card (support max. 256 G); NAS; SFTP
BrowserIE; Chrome; Firefox
Management SoftwareSmart PSS; DSS; DMSS
Mobile PhoneIOS; Android
Certification
CertificationsCE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
Power
Power Supply12V DC/PoE (802.3af)
Power Consumption< 6.0W
Environment
Operating Conditions–40 °C to +60 °C (–40 °F to +140 °F)/less than ≤ 95% RH
Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Protection GradeIP67
Structure
CasingMetal
Dimensions166.2 mm × Φ70 mm (6.5" × Φ2.8")
Net Weight0.473 kg (1.0 lb)
Gross Weight0.574 kg (1.3 lb)
