IPC-HDW4431EM-ASE-0280B
341.73 azn
Haqqında
Dahua IPC-HDW4431EM-ASE-0280B 4 MP səsli IP kamera; Piksel 2688×1520; IR işıqlandırma - 50 m; F2.8 mm; Bucaq-104°;
| Növ | IP |
| Meqapixel | 4 MP |
| Mikrofon | Mic |
| İşıqlandırma məsafəsi | 50 m |
| Obyektiv | Sabit |
| Fokus | 2.8 |
| İşıqlandırma | İR |
| Qoruma | IP67 |
| Material | Metal |
Ətraflı
| Technical Specification |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detetion | Off /On (4 Zone, Rectangle) |
| Region of Interest | Off /On (4 Zone) |
| Electronic Image Stabilization (EIS) |
N/A |
| Smart IR | Support |
| Defog | N/A |
| Digital Zoom | 16x |
| Flip | 0°/90°/180°/270° |
| Mirror | Off /On |
| Privacy Masking | Off /On (4 Area, Rectangle) |
| Audio | |
Compression |
G.711a/ G.711Mu/ AAC/ G.726 |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
Protocol | HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP |
| Interoperability | ONVIF, PSIA, CGI |
| Streaming Method | Unicast /Multicast |
| Max. User Access | 10 Users / 20 Users |
Edge Storage | NAS Local PC for instant recording Mirco SD card 128GB |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS, DSS, Easy4ip |
| Smart Phone | IOS, Android |
| Certifications | |
Certifications | CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15Subpart B |
| Interface | |
| Video Interface | N/A |
| Audio Interface | Built-in Mic |
| RS485 | N/A |
| Alarm | N/A |
| Electrical | |
| Power Supply | DC12V, PoE(802.3af)(Class 0) |
| Power Consumption | <5.5W |
Camera
| Image Sensor | 1/3” 4Megapixel progressive scan CMOS |
| Effective Pixels | 2688(H)x1520(V) |
| RAM/ROM | 512MB/32MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s |
| Minimum Illumination | 0.06Lux/F1.6( Color,1/3s,30IRE) 0.4Lux/F1.6( Color,1/30s,30IRE) 0Lux/F1.6(IR on) |
| S/N Ratio | More than 50dB |
| IR Distance | Distance up to 50m (164ft) |
| IR On/Off Control | Auto/ Manual |
| IR LEDs | 1 |
Lens
| Lens Type | Fixed | ||||
| Mount Type | Board-in | ||||
| Focal Length | 2.8mm (3.6mm,6mm optional) | ||||
| Max. Aperture | F1.6 (F1.6, F1.6) | ||||
| Angle of View | H:104° (83°, 55°), V:58° (45°, 31°) | ||||
| Optical Zoom | N/A | ||||
| Focus Control | Fixed | ||||
| Close FocusDistance | 1.1m (1.5m, 3.1m) | ||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.8 mm | 56m(184ft) | 22m(72ft) | 11m(36ft) | 6m(20ft) | |
| 3.6 mm | 80m(262ft) | 32m(105ft) | 16m(52ft) | 8m(26ft) | |
| 6.0 mm | 120m(394ft) | 48m(157ft) | 24m(79ft) | 12m(39ft) | |
Pan/Tilt/Rotation
| Pan/Tilt/Rotation Range | Pan:0˚~360˚; Tilt:0˚~78˚; Rotation:0˚~360˚ |
Intelligence
| IVS | Tripwire, Intrusion, Object Abandoned/Missing |
| Advanced Intelligent Functions | Face Detection |
Video
| Compression | H.265+/H.265/H.264+/H.264 |
| Streaming Capability | 3 Streams |
Resolution | 4M(2688×1520)/3M(2304×1296)/ 1080P(1920×1080)/1.3M(1280x960)/ 720P(1280×720)/D1(704×576/704×480)/ VGA(640×480)/CIF(352×288/352×240) |
Frame Rate | Main Stream: 4M(1~25/30fps) |
| Sub Stream: D1(1~25/30fps) | |
| Third Stream:720P(1~25/10fps) | |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264: 24K ~ 10240Kbps H.265: 14K ~ 9984Kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC Mode | BLC / HLC / WDR(120dB) |
| Environmental | |
| Operating Conditions | -30° C ~ +60° C (-22°F ~ +140° F) / Less than95% RH |
| Strorage Conditions | -30° C ~ +60° C (-22°F ~ +140° F) / Less than95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | N/A |
| Construction | |
| Casing | Metal |
| Dimensions | Φ106mm×93.7mm (4.17”×3.69”) |
| Net Weight | 0.47Kg (1.04lb) |
| Gross Weight | 0.65Kg (1.43lb) |
