Dahua IPC-HDW1430T1P-0280B-S5

IPC-HDW1430T1P-0280B-S5

197.22 azn

Dahua

4 MP

30 m

Sabit

2.8

İR

IP67

Metal

IPC-HDW1430T1P-0280B-S5

Stokda yoxdur

Haqqında

Dahua IPC-HDW1430T1P-0280B-S5 4 MP IP kamera; Piksel 2688×1520; IR işıqlandırma - 30 m; F2.8 mm; Bucaq-90°;

Növ	IP
Meqapixel	4 MP
İşıqlandırma məsafəsi	30 m
Obyektiv	Sabit
Fokus	2.8
İşıqlandırma	İR
Qoruma	IP67
Material	Metal

Ətraflı

Model		IPC-HDW1430T1P-0280B-S5
Camera
Matrix		1/3" CMOS
Effective pixels		2560×1440
ROM		16 MB
RAM		64 MB
Scanning system		Progressive
Electronic shutter speed		Auto / Manual 1 / 3 s – 1 / 100,000 s
Min. lighting		0.03 Lux at F2.0 (Color, 30 IRE) 0.003 Lux at F2.0 (B/W, 30 IRE) 0 Lux
Signal/Noise Ratio		>56 dB
IR distance		30 m (98.43 ft)
IR control On / Off		Auto / Manual
IR LEDs		1
Pan/Tilt/Rotate Range		Pan:0°–355° Tilt:0°–78° Rotation:0°–355°
Lens
Lens type		Fixed
Mounting type		M12
Focal length		2.8 mm
Max. diaphragm		F2.0
Viewing angle		Horizontal:90°; Vertical:50°; Diagonal:107°
IR control		Fixed
Closed focal length		1 m (3.28 ft)
DOOR Distance	Lens	Detection	Notification	Recognition	Identification
	2.8 mm	68.0 m (223.10 ft)	27.2 mm (89.24 ft)	13.6 m (44.62 ft)	6.8 m (22.31 ft)
Video
Video compression		N.265; H.264; H.264B; MJPEG (Only supported by additional stream)
Smart Codec		Smart H.265+; Smart H.264+
Video frame rate		Main stream: 2560 × 1440 (1 – 25 / 30 fps) Additional. stream: 704 × 576 (1 – 25 fps) / 704 × 480 (1 – 30 fps) * The above values are the max. frame rates of each stream; for multiple streams, the values will depend on the total encoding capacity.
Streaming Features		2 streams
Permission		4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240)
Data transfer rate control		CBR/VBR
Video bit rate		H.264:32 kbps–4096 kbps H.265:12 kbps–4096 kbps
Day Night		Auto (IR) / Color / B/W
BLC		Eat
HLC		Eat
WDR		DWDR
White Balance		Auto; Natural light; Street light; On open air; Manually; Regionally
Gain control		Auto / Manual
Noise suppression		3D NR
Motion Detection		Off / On (4 Zones, Rectangle)
Area of Interest (RoI)		Yes (4 Zones)
Smart lighting		Eat
Frame rotation		0° / 180° (0° default)
Display		Eat
Privacy mask		4 Zones
Audio
Built-in microphone		Eat
Audio compression		G.711a; G.711Mu; G.726; PCM
Anxiety
Alarming events		Network shutdown; IP conflict; Illegal access; Motion Detection; Video violation; Security Exception
Net
Network port		RJ-45 (10/100 Base-T)
SDK and API		Eat
Network protocol		IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast
Compatibility		ONVIF (Profile S / Profile T); CGI; P2P
User/Host		6 (Total bandwidth: 24 MB)
Storage		FTP
Browser		IE Chrome Firefox
Management software		Smart PSS; DSS; DMSS
Smartphones		iOS; Android
Cyber security		Configuration encryption; trusted execution; Digest; security logs; HTTPS; trusted update; WSSE; trusted boot; Account blocking; Generate and import X.509 certificate; Video encryption
Protection
Degree of protection		IP67
Certificates
Certificates		CE-LVD:EN 62368-1 CE-EMC:Electromagnetic Compatibility Directive 2014/30/EU FCC:47 CFR FCC Part 15 Subpart B
Environment
Operating temperature		–40 °C to +60 °C (–40 °F to +140 °F)
Operating humidity		≤95%
Storage temperature		–40 °C to +60 °C (–40 °F to +140 °F)
Electrical properties
Power supply		12 VDC / PoE (802.3af)
Power consumption		Basic: 1.6 W (12 VDC); 2.4 W (PoE) Max. (ICR + H.265+IR Intensity): 3.6 W (12 VDC); 4.7 W (PoE)
General information
Frame		Metal+Plastic
Color		White
Dimensions		85.5 mm × Φ109 mm (3.37" × Φ4.29")
Net weight		0.25 kg (0.55 lb)
Gross weight		0.38 kg (0.83 lb)
