IPC-B122-APF28-ECO
40.57 azn
Uniview
IP
2 MP
Mic
Sabit
2.8
İR
30 m
IP67
Plastik
Haqqında
IPC B122-APF28-ECO 2MP 2.8MM IR 30M,128GB Micro SD card ,Built-in Mic Bullet Network Kamera UNIARC
Növ | IP |
Meqapixel | 2 MP |
Mikrofon | Mic |
Obyektiv | Sabit |
Fokus | 2.8 |
İşıqlandırma | İR |
İşıqlandırma məsafəsi | 30 m |
Qoruma | IP67 |
Material | Plastik |
Ətraflı
IPC-B122-APF28 | ||||||
Camera | ||||||
Sensor | 1/2.8", progressive scan, CMOS | |||||
Lens | 2.8mm@F2.1 | |||||
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | ||
2.8 | 43.4 | 17.4 | 8.7 | |||
4.0 | 62.1 | 24.8 | 12.4 | |||
Angle of View (H) | 106.7° | |||||
Angle of View (V) | 57.1° | |||||
Angle of View (O) | 115.7° | |||||
Adjustment angle | Pan: 0° ~ 360° | Tilt: 0° ~ 90° | ||||
Shutter | Auto/Manual, 1 ~ 1/100000s | |||||
Minimum Illumination | Colour: 0.02Lux (F2.1, AGC ON) 0Lux with IR on | |||||
Digital noise reduction | 2D/3D DNR | |||||
Day/Night | IR-cut filter with auto switch (ICR) | |||||
S/N | >52dB | |||||
IR Range | Up to 30m (98ft) IR range | |||||
Defog | Digital Defog | |||||
WDR | DWDR | |||||
Audio | ||||||
Audio Compression | G.711 | |||||
Suppression | Supported | |||||
Sampling Rate | 8KHZ | |||||
Video | ||||||
Video Compression | Ultra 265, H.265, H.264 | |||||
H.264 code profile | Baseline profile, Main profile, High profile | |||||
Frame Rate | Main Stream: 1080P (1920*1080), Max 25fps; 720P (1280*720), Max 25fps; Sub Stream: D1 (720*576), Max 25fps; 640*360,Max 25fps; 2CIF(704*288), Max 25fps; CIF(352*288), Max 25fps; | |||||
HLC | Supported | |||||
BLC | Supported | |||||
OSD | Up to 4 OSDs | |||||
Privacy Mask | Up to 4 areas | |||||
ROI | Up to 8 areas | |||||
Motion Detection | Up to 4 areas | |||||
Network | ||||||
Protocols | IPv4, IGMP, ICMP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, UPnP, HTTP, RTMP | |||||
Compatible Integration | ONVIF (Profile S, Profile T), API | |||||
Interface | ||||||
Network | 10/100M Base-TX Ethernet | |||||
Built-in Mic | Supported | |||||
General | ||||||
Power | DC 12V±25%, PoE | |||||
Power consumption: Max 3.5W | ||||||
Dimensions (L × W × H) | 144 × 60 × 65mm (5.6” × 2.4” × 2.6”) | |||||
Weight | 0.17kg (0.37lb) | |||||
Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |||||
Surge Protection | 4KV | |||||
Ingress Protection | IP67 | |||||
Reset Button | N/A |
