iDS-7232HQHI-M2/S
739.57 azn
Stokda yoxdur
Haqqında
| Növ | XVR |
| Kanal sayı | 32 kanal |
| Meqapixel | 4 MP |
| Max HDD sayı | 2 HDD |
| Max HDD həcmi | 10 TB |
Ətraflı
| Model | iDS-7216HQHI-M2/S |
| Motion Detection 2.0¹ | |
Human/Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarmscaused by objects like leaves and lights; Quick search by object or event typeis supported; |
| Perimeter Protection¹ | |
| Human/Vehicle Analysis | Up to 4-ch |
| Recording | |
| Video compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
Encoding resolution | Main stream: When 1080pLite mode not enabled: For 4 MP stream access: 4 MP lite@15 fps; 1080plite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30fps (N) For 3MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps For 1080pstream access: 1080p/720p@15 fps;VGA/WD1/4CIF/CIF@25 fps (P)/30fps (N) For 720p streamaccess: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) When1080p Lite modeenabled: 4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps(P)/30 fps (N) |
Sub-stream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N) | |
| Video bitrate | 32 Kbps to 6 Mbps |
| Dual stream | Support |
| Stream type | Video, Video &Audio |
| Audio compression | G.711u |
| Audio bitrate | 64 Kbps |
| Video and Audio | |
IP video input2 | 2-ch (upto 18-ch)
Enhanced IP mode on: 8-ch (up to 24-ch),each up to 4 Mbps |
| Up to 6 MP resolution | |
| Support H.265+/H.265/H.264+/H.264 IP cameras | |
Analog videoinput | 16-ch |
| BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection | |
HDTVI input | 3K@20 fps, 4 MP@30 fps, 4 MP@25 fps, 3 MP@18 fps, 1080p@30 fps, 1080p@25 fps,720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps *: The 3 MP signal input is only available for channel 1/2 of iDS-7208HQHI-M2/S, and for channel 1/2/3/4of iDS-7216HQHI-M2/S. |
AHD input | 4 MP@25 fps, 4MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
HDCVI input | 4 MP@25 fps, 4 MP@30fps, 1080p@25 fps, 1080p@30 fps, 720p@25fps, 720p@30 fps |
| CVBS input | PAL/NTSC | |
CVBS output | 1-ch, BNC (1.0Vp-p, 75 Ω), resolution: PAL:704 × 576,NTSC: 704 × 480 | |
| HDMI output | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz | |
| VGA output | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz | |
| Video outputmode | HDMI/VGA simultaneous output | |
Audio input3 | 1-ch (up to 8-ch is optional), RCA (2.0 Vp-p, 1 KΩ) | 1-ch (up to 16-chis optional), RCA (2.0 Vp- p, 1 KΩ) |
| 8-ch via coaxial cable | 16-ch via coaxial cable | |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) | |
| Two-way audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (usingthe first audioinput) | |
| Synchronous playback | 8-ch | 16-ch |
| Network | ||
| Remote connection | 64 | 128 |
Network protocol | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF | |
Network interface | 1, RJ45 10/100Mbps self-adaptive Ethernet interface | 1,RJ45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Wi-Fi | Connectable to Wi-Fi network by Wi-Fi dongle through USB interface | |
| Auxiliary interface | ||
| SATA | 2 SATA interfaces, up to 10 TB capacity for each disk | |
| Serial interface | RS-485 (half-duplex) | |
USB interface | Front panel: 1 × USB 2.0; Rear panel:1 × USB 2.0 | Front panel: 1 × USB 2.0; Rear panel:1 × USB 3.0 |
| Alarm in/out3 | N/A (optional to support ) | |
| General | ||
| Power supply | 12 VDC, 2.5 A | 12 VDC, 3.3 A |
| Consumption (without HDD) | ≤ 30 W | ≤ 40 W |
| Working temperature | -10 °C to 55 °C(14 °F to 131 °F) | |
| Working humidity | 10% to 90% | |
| Dimension (W × D × H) | 380 × 320 × 48 mm (15.0” × 12.6” × 1.9”) | |
| Weight (without HDD) | ≤ 1.78 kg (3.9 lb.) | ≤ 2 kg (4.4lb.) |
739.57 azn
Stokda yoxdur
