HAC-HFW1509CP-A-LED-0280B
HAC-HFW1509CP-A-LED-0280B

109.03 azn

Dahua
Analoq
5 MP
LED
Sabit
2.8
20 m
Mic
IP67
Metal
109.03

1

Səbətə at AZN

HAC-HFW1509CP-A-LED-0280B

HAC-HFW1509CP-A-LED-0280B

Haqqında

Dahua HAC-HFW1509CP-A-LED-0280B 5 MP HD-CVI Full Color (rəngli) səsli kamera; Piksel 2880x1620; IR işıqlandırma - 20 m; F2,8 mm; Bucaq-112°; Audio (mikrofon)

Növ Analoq
Meqapixel 5 MP
İşıqlandırma LED
Obyektiv Sabit
Fokus 2.8
İşıqlandırma məsafəsi 20 m
Mikrofon Mic
Qoruma IP67
Material Metal

Ətraflı

Camera
Image Sensor5MP CMOS
Max. Resolution2880 (H) × 1620 (V)
Pixel5MP
Scanning SystemProgressive
Electronic Shutter Speed

PAL:1/3 s–1/100,000 s

NTSC:1/4 s–1/100,000 s

S/N Ratio> 65 dB
Min. Illumination0.001 Lux/F1.0, 0 Lux warm light on
Illumination Distance20 m (65.61 ft)
Illuminator On/Off ControlAuto; manual
Illuminator Number1
Pan/Tilt/Rotation RangePan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens TypeFixed lens
Mount TypeM12
Focal Length2.8 mm; 3.6 mm
Max. ApertureF1.0
Field of View2.8 mm: H: 112°; V: 57°; D: 132°
3.6 mm: H: 88; V: 46°; D: 104°
Iris TypeFixed iris
Close Focus Distance2.8 mm: 1.6 m (5.25 ft);
3.6 mm: 2.3 m (7.5 ft)
DORI DistanceLensDetectObserveRecognizeIdentify
2.8 mm

67.4 m

(212.3 ft)

27.0 m

(88.6 ft)

13.5 m

(44.3 ft)

6.7 m

(22.0 ft)

3.6 mm

80.0 m

(262.5 ft)

32.0 m

(105.0 ft)

16.0 m

(52.5 ft)

8.0 m

(26.2 ft)

Video
Frame RateCVI:
PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps
NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H
Resolution5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
BLCBLC/HLC/WDR/HLC-Pro
WDR120 dB
White BalanceAuto; manual
Gain ControlAuto; manual
Noise Reduction3D NR
Smart LightYes
MirrorOff/On
Privacy MaskingOff/On (8 areas, rectangle)
Certifications
CertificationsCE (EN55032, EN55024, EN50130-4,EN60950-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Video OutputVideo output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio InputOne channel built-in mic (-A)
Power
Power Supply12 V ±30% DC
Power ConsumptionMax 4.4 W (12 V DC, warm light on)
Environment
Operating Temperature–40 °C to +60 °C (–40 °F to +140 °F); < 95% (non-condensation)
Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F); < 95% (non-condensation)
Protection GradeIP67
Structure
CasingMetal front cover + plastic main body + plastic bracket
Camera Dimensions161.3 mm × 69.7 mm × 70.0 mm (6.35" × 2.75" × 2.75")
Net Weight0.23 kg (0.51 lb)
Gross Weight0.33 kg (0.73 lb)
