HAC-HDW1200CLQP-IL-A

HAC-HDW1200CLQP-IL-A

Haqqında

DAHUA HAC-HDW1200CLQP-IL-A 2MP Smart Dual Light HDCVI Fixed-focal Eyeball Camera

Növ Analoq
Meqapixel 2 MP
Mikrofon Mic
Obyektiv Sabit
Fokus 2.8
İşıqlandırma LED
İşıqlandırma məsafəsi 20 m
Qoruma IP67
Material Plastik

Ətraflı

Camera
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Scanning SystemProgressive
Electronic Shutter SpeedPAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s
Min. Illumination0.01 lux@F2.0 (Color, 30 IRE)
0.001 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio>65 dB
Illumination Distance

IR: 20 m (65.62 ft)

Warm light: 20 m (65.62 ft)

Illuminator On/Off ControlAuto
Illuminator Number2 (Warm light); 2 (IR light)
Angle AdjustmentPan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens TypeFixed-focal
Auto FocusNo
Lens MountM12
Focal Length2.8 mm;3.6 mm
Max. ApertureF2.0
Field of View2.8 mm: H: 102°; V: 60°; D: 129°
3.6 mm: H: 83°; V: 48°; D: 105°
Iris ControlFixed
Close Focus Distance2.8 mm: 0.5 m (1.64 ft)
3.6 mm: 0.7 m (2.30 ft)
DORI DistanceLensDetectObserveRecognizeIdentify
2.8 mm

41.1 m

(135.83 ft)

16.5 m

(42.13 ft)

8.3 m

(27.23 ft)

4.1 m

(13.45 ft)

3.6 mm

50.9 m

(166.99 ft)

20.3 m

(66.60 ft)

10.2 m

(33.46 ft)

5.1 m

(16.73 ft)

Video
Video Frame RateCVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960H;
NTSC: 960H
Resolution1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/NightAuto(ICR)/Color/B/W
BLCBLC; HLC; DWDR
WDRDWDR
White BalanceAuto;Area white balance
Gain ControlAuto
Noise Reduction3D NR
Illumination ModeSmart IR&WL; WL Mode; IR Mode
MirrorYes
Privacy MaskingOff/On (8 areas, rectangle)
Certification
CertificationsCE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035;
FCC: 47 CFR FCC Part 15, Subpart B
Port
Video OutputVideo output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Input1 channel
Power
Power Supply12 VDC ± 30%
Power ConsumptionMax 2.6W (12 VDC, IR on)
Environment
Operating Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity<95% (RH), non-condensing
Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity<95% (RH), non-condensing
ProtectionIP67
Structure
Casing MaterialPlastic
Product DimensionsΦ97.1 mm × 93.8 mm (Φ3.82" × 3.69")
Net Weight0.18 kg (0.40 lb)
Gross Weight0.29 kg (0.64 lb)
InstallationWall mount; ceiling mount; vertical pole mount
