GNT-P9206EA
73.89 azn
Haqqında
GNT-P9206EA 4p 2Up-Link 250m AI PoE Switch Genata
| PoE gücü | 60 W |
| Port sayı | 5 Port |
| PoE | PoE |
| Port sürəti | 100mb/s |
Ətraflı
| GNT-P9206EA | Product Features |
Total 65W PowerSupply 4 ports PoE 2 ports Uplink | AI Watchdog Function 6KV Lightning &8KV ESD Protection Support bt 60W High Power Auto-Adaption 250m Transmission |
| Specifications | |
| Ports | PoE (1~3):10/100Mbps PoE ports(RJ45) PoE (4):10/100Mbps PoE port (RJ45),Support bt 60W High Power LAN (1~2):10/100Mbps uplink ports (RJ45) |
| Transmission Rate | 200Mbps Full Duplex; 10 or 100MbpsHalf Duplex |
| Transmission Distance | 100Mbps /10Mbps, Auto-Adaption 250m |
| Performance Specification | Bandwidth:1.2Gbps Network Latency (10 to 100Mbps): <= 16μs (use the 64bytepackage size) MAC address table: 2K The Frame Filter& Transmission Rate:14800pps the mostfor 10M port, 148800pps the most for 100M port |
| Networking Standard | IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3x FlowControl IEEE 802.3af/at/bt Powerover Ethernet |
| Power Support | Power Input: AC 90~240VTotal≤65W AI Watchdog: Port1~4 Power Output: PoE1~3Port:1/2(+52V),3/6(GND)≤30W PoE 4 Port:1245(+53V),3678(GND) Compatible1/2(+52V),3/6(GND)≤60W |
| Protection Level | Lightning Protection:6KV, Per:IEC61000-4-5 ESD Protection:8KV, Per: IEC61000-4-2 |
| Physical Specifications | Size(L*W*H): 187mm*139mm*43mm, Weight:1.0KG |
| Working Environment | OperatingTemperature: -30℃~60℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% Non-condensing Storage Humidity: 5%~90% Non-condensing |
| Certification | CEMark FCC Part15, ClassB RoHS 2.0 |
| Package Content | AC Power Cable,User Manual |
