GNT-P1012G6-F
202.68 azn
Haqqında
GNT-P1012G6-F 8pGb +2SFP AI Gigabit Waterproof PoE Switch Genata
| PoE gücü | 120 W |
| Port sayı | 8 Port |
| PoE | PoE |
| Port sürəti | 1000mb/s |
Ətraflı
| GNT-P1012G6 | Product Features |
Total 120W PowerSupply 8 ports PoE 2 ports Uplink 2 ports SFP | AI Watchdog Function 6KV Lightning &8KV ESD Protection Support bt 60W High Power |
| Specifications | |
| Ports | PoE (1~6):10/100/1000Mbps PoE ports (RJ45) PoE (7~8):10/100/1000Mbps PoE ports (RJ45),Support bt 60W High Power LAN (1~2):10/100/1000Mbps uplink ports (RJ45) SFP (1~2):10/100/1000Mbps SFP ports |
| Transmission Rate | 2000Mbps Full Duplex; 10 or 100 or 1000 Mbps HalfDuplex |
| Transmission Distance | 130m |
| Performance Specification | Bandwidth:24Gbps NetworkLatency (10 to 1000Mbps): 16μs(use the 64bytepackage size) MAC address table: 8K The Frame Filter& Transmission Rate:14800pps the mostfor 10M port, 148800pps the mostfor 100M port;1488000pps the most for1000M port |
| Networking Standard | IEEE 802.3i 10BASE-T/IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3x FlowControl IEEE 802.3af/at/bt Powerover Ethernet |
| Power Support | Power Input: AC 90~240VTotal≤120W AI Watchdog: Port1~8 Power Output: PoE1~6Port:1/2(+52V),3/6(GND)≤30W PoE7~8 Port:1245(+53V),3678(GND) Compatible1/2(+52V),3/6(GND)≤60W |
| Protection Level | Lightning Protection:6KV, Per: IEC61000-4-5 ESD Protection:8KV, Per: IEC61000-4-2 |
| Physical Specifications | Size(L*W*H): 187mm*139mm*43mm, Weight:1.0KG |
| Working Environment | OperatingTemperature: -30℃~60℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% Non-condensing Storage Humidity: 5%~90% Non-condensing |
| Certification | CEMark FCC Part15, ClassB RoHS 2.0 |
| Package Content | AC Power Cable,User Manual |
