DS-7208HGHI-K1
DS-7208HGHI-K1

178.52 azn

Hikvision
XVR
8 kanal
2 MP
1 HDD
4 TB

Stokda yoxdur

DS-7208HGHI-K1

Stokda yoxdur
DS-7208HGHI-K1

Haqqında

DS-7208HGHI-K1 DIGITAL VIDEO RECORDER HIKVISION

Növ XVR
Kanal sayı 8 kanal
Meqapixel 2 MP
Max HDD sayı 1 HDD
Max HDD həcmi 4 TB

Ətraflı

Motion Detection 2.0





Human/Vehicle Analysis

Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves andlights;

Quick search by object or event typeis supported;

Recording
Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264





Encoding Resolution

For 1080p streamaccess: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF For 720p streamaccess: 720p/WD1/4CIF/VGA/CIF

For SD stream access:WD1/4CIF/VGA/CIF











Frame Rate

Main stream:

For 1080p streamaccess: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fpsFor 720p streamaccess: 720p/WD1/4CIF/VGA/CIF@15 fps

For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Sub-stream:

For 1080pand 720p streamaccess: CIF/QVGA@15 fps

For SD stream access:CIF/QVGA@25 fps (P)/30fps (N)

Video Bitrate32 Kbps to 4 Mbps
Stream TypeVideo, Video& Audio
Audio CompressionG.711u
Audio Bitrate64 Kbps
Video and Audio





IP Video Input

2-ch (upto 10-ch)

Up to 5 MP resolution

Support H.265+/H.265/H.264+/H.264 IP cameras



Analog VideoInput

8-ch

BNC interface (1.0 Vp-p,75 Ω), supporting coaxitron connection

HDTVI Input1080p25, 1080p30, 720p25, 720p30
AHD Input1080p25, 1080p30, 720p25,720p30
HDCVI Input1080p25, 1080p30, 720p25,720p30
CVBS InputSupport
HDMI Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 ×720/60Hz
VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 ×720/60Hz
Video OutputModeHDMI/VGA simultaneous output



Audio Input

1-ch RCA (2.0Vp-p, 1 KΩ)

8-ch via coaxial cable

Audio Output1-ch, RCA (Linear, 1 KΩ)
Two-Way AudioReuse the firstaudio input
Synchronous playback8-ch
Network
Total Bandwidth72 Mbps
Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS
Remote Connection64
Network Interface1, RJ45 10/100Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA1 SATA interface
CapacityUp to 4 TB capacity for each disk
USB InterfaceRear panel: 2 × USB 2.0
Alarm In/OutN/A
General
Power Supply12 VDC, 1.5 A
Consumption≤ 17 W (without HDD)
Working Temperature-10 °C to 55 °C (14 °F to +31 °F)
Working Humidity10% to 90%
Dimension (W × D × H)260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight≤ 1 kg (without HDD, 2.2 lb.)

178.52 azn

Hikvision
XVR
8 kanal
2 MP
1 HDD
4 TB

Stokda yoxdur
