DS-7104HQHI-K1
176.82 azn
Stokda yoxdur
Haqqında
DS-7104HQHI-K1 2MP HD TVI DIGITAL VIDEO RECORDER HIKVISION
| Növ | XVR |
| Kanal sayı | 4 kanal |
| Meqapixel | 2 MP |
| Max HDD sayı | 1 HDD |
| Max HDD həcmi | 4 TB |
Ətraflı
| Model | DS-7104HQHI-K1 |
| Video compression | H.265+/H.265/H.264+/H.264 |
| Analog video input | 4-ch |
| BNC interface (1.0 Vp-p,75 Ω), supporting coaxitron connection | |
| HDTVI input | 3 MP,1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 Note: The 3 MP signal input is only available for channel 1 of DS-7104HQHI-K1, |
| AHD input | 1080p25, 1080p30, 720p25, 720p30 |
| HDCVI input | 1080p25, 1080p30, 720p25, 720p30 |
| CVBS input | Support |
IP videoinput | 1-ch |
| Up to 4 MP resolution | |
| Supports H.265+/H.265/H.264+/H.264 IP cameras | |
| Audio compression | G.711u |
| Audio input/Two-way audio input | 1-ch, RCA (2.0 Vp-p,1 KΩ) |
HDMI/VGA output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024× 768/60Hz |
| Encoding resolution | When 1080p Lite mode not enabled: 3 MP/1080p/720p/WD1/4CIF/VGA/CIF; When 1080pLite mode enabled: 3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF |
Frame rate | Main stream: When 1080pLite mode not enabled: For 3 MP streamaccess: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080pstream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p streamaccess: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080pLite mode enabled: 3 MP@15fps 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps(P)/30fps (N) |
Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) | |
| Video bit rate | 32 Kbps to 6 Mbps |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Audio bit rate | 64 Kbps |
| Dual stream | Support |
| Stream type | Video, Video& Audio |
Synchronous playback | 4-ch |
| Remote connections | 128 |
| Network protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP,SADP, NFS, iSCSI,UPnP™, HTTPS, ONVIF |
| SATA | 1 SATA interface |
| Capacity | Up to 4 TB capacity for each disk |
Network interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
| USB interface | Real panel: 2 × USB 2.0 |
| Power supply | 12 VDC |
| Consumption (without HDD) | ≤ 8 W |
| Working temperature | -10 ºC to +55 ºC (+14 ºF to +131 ºF) |
Working humidity | 10% to 90% |
| Dimensions (W × D × H) | 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch) |
| Weight (without HDD) | ≤ 1 kg (2.2 lb) |
176.82 azn
Stokda yoxdur
