DS-3E1326P-EI
697.07 azn
Yeni
Haqqında
DS-3E1326P-EI 24p Unmanaged Fast Ethernet Smart POE Switch HIKVISION
| Port sayı | 24 Port |
| Tip | Smart |
| PoE | PoE |
| PoE gücü | 400 W |
| Port sürəti | 100mb/s |
Ətraflı
| General | |
| Shell | Metal material |
| Net Weight | 2.83 kg (6.24 lb) |
| Gross Weight | 3.8 kg (8.38 lb) |
| Dimensions (W × H × D) | 440.00 mm × 44.00 mm × 220.80 mm (17.32'' × 1.73'' × 8.69'') |
| Operating Temperature | 0 °C to 45 °C (0 °F to 113 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185°F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 100-240 V AC, 50/60 Hz, Max. 6.3 A |
| Max. Power Consumption | 400 W |
| Installation Mode | Rack (equipped with mounting ears) |
| Power Consumption in Idle | 30 W |
| Surge Protection | 6 kV |
| Network Parameters | |
| Ports | 24 × 10/100 Mbps PoE port,2× Gigabit combo |
| MAC Address Table | 16 K |
| Switching Capacity | Whole-Device Performance: 14.8 Gbps Port Performance: 8.8 Gbps |
| Packet Forwarding Rate | Whole-Device Performance: 11.01 Mpps Port Performance: 6.55 Mpps |
| Internal Cache | 4 Mbits |
| PoE Power Supply | |
| PoE Standard | IEEE 802.3af,IEEE 802.3at |
| PoE Power Pin | 8-pin power:1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| PoE Port | PoE: Ports1 to 24 |
| Max. Port Power | 30 W |
| PoE Power Budget | 370 W |
| Software Function | |
| Long Range | Ports 1 to 24: up to 300 m. Long rangeperformance may vary depend on camera model or cable condition. |
| VIP Port | Ports 1 to 8: data on VIP portsis preferentially forwarded when bandwidth resources are insufficient. |
Port Isolation | Ports 1 to 24: port isolation mode to improvenetwork security Ports in an isolation group cannot communicate with each other,but they can communicate with ports outside the isolation group. |
| PoE Watchdog | Ports 1 to 24: auto detectand restart the cameras that do not respond. |
Link Aggregation | Link aggregation is used to aggregate multiple physical ports to form a logical portfor load balancing, bandwidth expansion, and port protection. Support static linkaggregation. Support 1 aggregation group. |
Loop Prevention | Loop prevention is used to prevent theswitching network fromforming loops, which will seriously affect network communication. Disabled by default. Support 802.1D STP. Suppport 802.1wRSTP. |
VLAN | VLAN is usedfor network scaleplanning and network health improvement. Support 802.1Q. Configurable VLAN ID from 1-4094. Support Trunk,Access port mode. Support Max. 4094 VLAN. |
HPP | Support one-click activation and remotemanagement via Hik-Partner Pro. Functions supported:
|
System Maintenance | Support device management via web. Support DHCP Client.Enabled by defaultfor dynamic assignment of management IP addresses. Support Super IP,which is a fixed IP address (10.180.190.200) for direct access. Support management via Hik-Central Pro. Support remotemanagement via Hik-Partner Pro. Support cable detection. Abnormal open circuits and short circuits as well as network cable length can be detected. Supports 802.1ab LLDPfor peer device discovery. Support portmirroring for faultlocating. |
| Approval | |
EMC | CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035:2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015) |
| Safety | CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014(Second Edition)), CE-LVD(EN 62368-1: 2014+A11: 2017) |
| Chemistry | CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006) |
