DS-3E0528HP-E
746.37 azn
Haqqında
DS-3E0528HP-E 24 Port Gigabit Unmanaged POE Switch hikvision
| Port sayı | 24 Port |
| PoE | PoE |
| PoE gücü | 400 W |
| Port sürəti | 1000mb/s |
Ətraflı
| Model | DS-3E0528HP-E |
| Shell | Metal material |
| Net Weight | 2.98 kg (6.57 lb) |
| Dimensions (W × H × D) | 440.0 mm × 220.8 mm × 44.0 mm (17.32'' × 8.69'' × 1.73'') |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113°F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185°F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 100~240 V AC, 50/60 Hz, Max. 6.5 A |
| Max. Power Consumption | 400 W |
| Power Consumption in Idle | 30 W |
| Installation Mode | Desk-Mounted |
| Surge Protection | 6 kV |
| Ports | 24 × Gigabit PoE port,2× Gigabit RJ45port,2 × Gigabitfiber optical port |
| MAC Address Table | 8 K |
| Switching Capacity | 56 Gbps |
| Packet Forwarding Rate | 41.664 Mpps |
| Internal Cache | 4.1 Mbits |
| PoE Standard | IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt |
| PoE Port | Hi-PoE: Ports 1 to 4 PoE: Ports1 to24 |
| PoE Power Pin | 8-pin power:1/2(-), 3/6(+), 4/5(+),7/8(-) |
| Max. Port Power | Ports 1 to4: 90 W Ports 5 to 24: 30 W |
| PoE Power Budget | 370 W |
| Long Range | Ports 21 to 24: upto 300 m. Long rangeperformance may varydepend on cameramodel or cablecondition. |
Port Isolation | Ports 1 to 24: portisolation mode to improve network security. Ports in an isolation group cannot communicate with each other,but they can communicate with ports outside the isolation group. |
| PoE Watchdog | Ports 1 to 24: auto detect and restart the cameras that do not respond. |
EMC | FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020,EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue7:2020),RCM (AS/NZS CISPR32: 2015) |
| Safety | UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD(EN 62368-1: 2014+A11: 2017) |
| Chemistry | CE-RoHS (2011/65/EU) |
